RJ45 90degree 24 ports cat5e UTP Network patch panel fit for 23-28AWG Cables

Quick Detail:

1.Type:Category 5e UTP
2.Color:black 3.Port:24
4.IDC build -in times ≥250,RJ45 socket plug-pull times ≥750

5.Contact: PC UL94V-0, 0.45mm(0.018")

6.Fit for 22-26AWG (0.4-0.65mm) and 5.2inch(1.27mm) cables

7.3 u" Gold plating on contact area

Description:

1) Fore plate colors available: white
2) Transmission stability. Wholly Enclosed Shielded Patch Panel

3) Highly resistance and inflaming retarding plastics material, Grade UL94-0
4) It is applicable for 24*RJ45 Cat5e (UTP) keystone jack

5) Distinctive color labels on the module indicate universal wiring patterns for T568A and T568B.
6) Not fitted with module port can use blank dustproof stoppage, elegant appearance
7) Snap-in structure, Firm and easy installation reducing the installation and operation cost.

8) The back of the patch panel is fitted with cable manager for convenience of cable management

9) Cabinet designed, Label and inlaid marks for convenience of identification and supervision.

10) Strength core and shell was insulation, add with grounding lead

11) Module part is fitted with shield, protecting inner IDC contact from irregular working in rugged

environment.

Electrical:

Angle:90,180 Degree

Current rating: 1.5 Amp Max.

Voltage rating: 150 Volts

Contact resistance: 20 m-ohm

Insulation Resistance: 500M-ohm

Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min

Specifications:

Meet TIA/EIA-568-A and TIA/EIA-568-B Category 6A requirements.
Meet TIA/EIA TSB-40
Meet ISO/IEC Generic Cabling Standard 11801
Meet CENELEC Generic Cabling Standard EN50173

Materials:

Housing: PC UL94V-0

Termination: 110 Type
IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.
PCB: FR4 1.6mm(0.04") thickness, 2 layers
Contact: PC UL94V-0, 0.45mm(0.018") Diameter Phosphor bronze with 3 u" Gold plating on contact area.

Applications:

Patch management subsystem is the most important component is to achieve vertical lines and two horizontal cabling subsystem cross-connect hub.

for Structure Cabling System

Competitive Advantage:

As a factory,We supply goods: with stable quality good prices shorter delivery time less minimum order quantity.

We are running in networking business for nearly 10years,so our product of cabling are very rich,most of cabling accessories are available with us.

All our goods are sell abroad, and we support our customers with good service of rich experience,which will save much time&work.
