high tensile steel wire tecco Rockfall Mesh hillside stabil
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|
Slope Stabilization Mesh System rockfall mesh Ring or wire mesh
Ring wire mesh +TECCO MESH System
Tecco Mesh Specification:
Mesh shape:diamond
Material:high tensible carbon steel
Wire strength:1770Mpa
Wire diameter:3mm
Corrosion protection: 95%Zn-5%Al super coating
Coating:150g/m2
Mesh opening:103mm x 180mm
Breaking load of single wire:12.5KN
Tensile strength:110KN/m
Mesh edges knotted
Roll width:1m-3.5m
Roll length:10m or 30m
Weight:1.45kg/m2
High tensil steel wire mesh ( TECCO MESH ) and ring wire mesh
Ring wire mesh system is a passive protection system, a special branch,
which has a passive protection system than the average strength of a higher character.
The same applies to construction facilities in the buffer zone next to the mountains and little hills,
the rock fall, flying stones, avalanches, landslides blocked the building facilities,
building facilities to avoid the disasters on the destruction.
They can be installed with a low outlay of material and man hours,
greatly reducing costs and construction time. Emptying is simple.
ring form wire mesh(high quality)
materials:stainless steel, steel
general steel wire geogrids
Firm, Beautiful
ring form wire mesh(high quality)
material: stainless steel wire, steel wire
using:slope reinforcement
The whole system is composed of high-strength steel wire, bolt and other installation components.
sns protective mesh ,also known as safety netting system,is widely used in reinforcement,the system ,mainly made up of wire,enjoy the basic functions to cover and intercept so as to defend various geologic al disasters.
|
Slope Stabilization Mesh System Component & Characteristic |
|||
|
Type |
Mesh Type |
Structure Configure |
Function |
|
GAR1 Common Simple Type |
Steel Wire Netting |
Edge Steel Wire Anchor Rope+ Support Rope t + Oversewed Rope(D0/08/300 Steel netting + Anchor Rope+ Horizontal Supported Rope |
Protection, Restriction on the slope of rocks movement,Against the collapse |
|
GAR2 Common Type |
Steel Wire Netting |
System Steel Anchor Rope+ Support Rope + Oversewed Rope,Concave Orifice+ Anchor fixed + Horizontal Support Rope (2-16)+Steel Wire Netting08/300/4*4)+Oversewed Rope(8) |
Slope Reinforcement,Protect from collapse and weathering. |
|
GPS1 Common Use |
Steel Wire Netting+ Steel Wire Grid |
Same to GAR1+ Steel Wire Grid |
Same To GAR1, When there are small rocks. |
high tensile steel wire mesh(tecco mesh)+ring wire mesh
Debris flow protection fecen
