10KA Silver Short Mini Circuit Breaker With Moulded Case ,
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Zhejiang,China(Mainland) |
|---|
Silver Overload Short Mini Circuit Breaker With Moulded Case , Thermal Overload Relay
Quick Detail:
Place of Origin: Zhejiang China(Mainland)
Brand Name: JIELI Model Number: GWS
Type: Mini
Poles Number:1P,2P,3P
Model: JIELI
Parts: cooper/brass parts
Cover: fire proof
Point: silver /cooper point
Poles: 1P,2P,3P
Breaking capacity: 4.5KA, 6KA , 10KA
Current: 1A-5A, 6A-63A, 80A-125A
Certificate: CE/ISO9001/IEC60898-1
Description:
■Gewiss Mini Circuit Breaker has functions with protection against both overload and short circuit.
■Gewiss Mini Circuit Breaker has high breaking capacity with 6KA.
■Gewiss Mini Circuit Breaker Contact position indication
■Gewiss Mini Circuit Breaker is applicable to terminal and pin/fork type busbar connection.
Applications:
Gewiss Mini Circuit Breaker can be used for both home and industry, which is very convenient and effective. GWS miniature circuit breaker is manufactured by high-end material and the mechanical life is up to 10000.
Specifications:
Item name : | GWS |
Standard : | IEC60898/GB10963 |
Product Certifications : | CE,CB,3C |
Product Function : | Short circuit protection, Over current protection |
Rated current(A) : | 1A-5A, 6A-63A, 80A-125A |
No of pole : | 1P,2P,3P |
Rated voltage(V) : | 230/400V |
Rated frequency(Hz) : | 50/60 |
Fiducial temperature : | 30°C |
Environment temperature : | -35~70°C |
Installation style standard : | 35mm guide |
Connection type : | Tunnel style, Pin style, U style |
Biggest wiring ability : | 25mm2 |
Magnetic tripping curve : | B(3-5In),C(5-10In),D(10-20In) |
(ICU)Rated capacity of short circuit: | 6000 |
(ICS)Operation capacity of short circuit : | 6000 |
Mechanical life : | 10000 |
Electrical life : | 4000 |
Protection degree : | IP20 |
Competitive Advantage:
The performance of Gewiss Mini Circuit Breaker is good, and GWS’electrical life is 4000,mechanical life is up to 10000.
Gewiss Mini Circuit Breaker has a ready market in all countries.
Gewiss Mini Circuit Breaker, its magnetic tripping curve B(3-5In),C(5-10In),D(10-20In)
Gewiss Mini Circuit Breaker, the rated capacity of shortcircuit(ICU) is 6000.
About our company-JIELI
JIELI Electrical is abbreviation for"Alliance of JIELI Electrical Industry",with JIELI brand and ICEDC brand.
JIELI Electrical have 29 members and more than 2000employers,all of the plants area are about 50000square meters.
JIELI Electrical devoted in producing low-voltage circuit breaker and other related products.At present,
JIELI main products MCB,MCCB,RCCB,Distribution box,AC contactor,Relay,Switch and more than thousands electrical goods spare parts.
