Simple 1250mm Steel Slitting Line For steel coil 4mm Thickness and middle speed

  • Application:CR/HRC/stainless steel /galvanized
  • thickness of coil plate:1-4mm
  • width of coil plate:1250mm
  • coil weight:10MT(max)
  • line speed:0-40m/min

Specifications

Application: CR/HRC/stainless steel /galvanized and so on
thickness of coil plate: 1-4mm
width of coil plate: 1250mm
coil weight: 10MT(max)
coil I.D: ф508
coil O.D: ф1400mm
the diameter of slitting blade shaft ф160
slitting blade: φ180Xφ320X20
material of slitting blade: 9CrSi
the hardness of slitting blade: HRC58°-60°
recoiler I.D: φ508
power: 380V/50Hz/3Ph
tolerance of width error: ≤±0.05mm/2M
line speed 0-40m/min
area of the whole machine: 20m(L)x6m(W)
Production orientation from left to right

Composed devices

1. Hydraulic entry coil car --------Carry coils into the slitting line

2. Hydraulic un-coiler ---------Uncoiling the steel coil

3. Pinch and press device ---------Feed plates and pre-straightening the sheet

4. Hydraulic cutting machine --------cut the damage or irregular sheet head

5. Slitting machine -------- Slit the sheet into strips accordingly

6. Scrap winder ---------Wind the scrap which is slit on both sides

7. Tension device ----------Create the tension to improve the recoiling quality

8. Hydraulic recoiler ---------Recoiling the strips into coils seperately

9. Hydraulic exit coil car ---------Carry finished coils out of the production line

10. Electric control system

11. Hydraulic system

Applications:

1. ZJX-1-4X1250mm simple hydraulic Metal slitting line is used for slitting the CR/ HRC/ stainless steel / galvanized to prepare for the next process.

2. This is a Specific model slitting line with simple and automatic elements

3. This model is designed for the Hot rolled steel coils to prepare the material for the pipes or flat bars

4. Much Competitive in the design and price

Factory Images
