PI and PTFE online

PI Characteristics:

1.flame resistance

2.good mechanical properties

3.excellent thermal properties

4.high radiation-resistance

5.outstanding electrical properties

6.high temperature:250°C

7.dielectric properties

8.corrosion-resistance

PI Industry Applications:

1.Semiconductor machinery components

2.Aerospace parts

3.Seals

4.Pump and valve components

5.Bearings \ bushings \Gear

6. Electrical components

7.Medical instrument parts

8.Food processing machinery components

9.Oil intrutry

10. Automatic intrutry

Standard sizes:

0.5mx0.5m  1mx1m  1.2mx1.2m  2mx2m  0.5mx1m   1mx1.2m  1mx2m

Thickness: 1mm-100mm

Any specification is available, welcome to custom.

I. PTFE   Introduction

PTFE  comes with  unbelievable  chemical  resistance  against  almost  all chemicals except  for  some   fluorides and molten alkali metals.This  thermoplastic polymer  is  the most  initial  type  of  fluoroplastics and  has  the most  extensive  applications.

II. PTFE  Strength:

1.Prominent  flame  retardance   with   limiting  oxygen index  below 90.

2.Low  coefficient   of  friction.

3.Non-stick  properties  and  self-lubrcation.

4.Outstanding  resistance  to  temperature  ranged from  -200℃ to 260℃.

5.Excellent electrical insulation.

6.Remarkable  resistance  against  weather  and  aging.

7.High  gas  permeability.

8.Good  physiological   safety,bio  compatibility  and   preventing  thrombosis.

III. PTFE    Applications

1.Corrosion  resistance  materials  used  for  chemical   vessel   and   parts      such   as  tank,recation  kettle,lining,valve,pump  body, connector ,filter  material   and  parting  application.

2.Abrasion  resistance  parts   such  as   static  and  synamic  O-ring,piston  ring,washer,valve  support, bearing,bearing pad, sliding block and  guide  rail,etc.

3.Products   resistance     to  thermal,high  frequency  electricity  and  electric  arc,such  as  high   frequency, cable, moisture resistant  cable and capacitor,etc.

4.Graft materials such as artificial  blood vessel,artificial heart,artificial heart,artificial esophagus,artificial peritoneum,artificial heart and lung dialysis membrane,as well as all kinds of canulas and catheters,etc.

5.Non-stick coating materials for all kinds of non-stick cookware and non-stick rollers for food manufacture equipment.

I. MC Nylon  Introduction

Cast  Nylon is one time higher than  PA6(POLYAMIDE 6) in terms of molecular weight,whereby this kind of engineering plastic is twice as outstanding as PA6 in various properties,and own very low stress level.

Cast Nylon is the industry-proven wear material for manufacture of large products,espacially in small volume,various types and complex structures,such as large gears,sliding bearing,mid to high-speed load-carrying bearing,roller,valve sear and guide rail,etc.

Addtionally,this poluamide product is also the cost feeective solution for expensive manufacture of mould.

II. MC Nylon  Strength

1.Remarkable rigidity,hardness and toughness.

2.Outstanding impact resistance and notch  toughness.

3.Thermal stability and  stress-cracking  resistance.

4.Excellent resistance against aging and abrasion .

5.Prominent shock absorption.

6.Self-lubricating comes with low coeffcient of friction and noise generation.

7.Superior machinability and dimensional atability.

8.Utmost creep resistance for precise control.

9.Sailent chemical insulation and capactiy for printing and coloring .

10.Non-toxic.

III. MC Nylon   Application

1.Bearing , axle  sleeve,bushing,gear,planet gear,rack,caster,pump body

2.Automobile parts such as lock,chain wheel,housing,etc.

3.Sliding track,roller,hardware parts,transmission parts,household appliance parts

4.Fan blade,structural panel,wear pad

5.Parts for chemical machinery and anticorrosive equipment.

6.Screw,rubber roller.
