2x2 Bypass Mechanical Fiber Optic Switch
  • 2x2 Bypass Mechanical Fiber Optic Switch
2x2 Bypass Mechanical Fiber Optic Switch

2x2 Bypass Mechanical Fiber Optic Switch

Payment Type:
T/T
Incoterm:
FOB
Min. Order:
2 Piece/Pieces
Min. Order:
2 Piece/Pieces
Delivery Time:
7 Days
Transportation:
Air
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: shenzhen
Productivity: 2000pcs
Supply Ability: 2000pcs
Payment Type: T/T
Incoterm: FOB
Certificate: CE,ROSE
Transportation: Air
Product Description
Product Description

Flyin Optronics` 2×2B Mechanical Fiber Optic Switch (2X2B Optical Switch) connects optical channels by redirecting an incoming optical signal into a selected output fiber. This is achieved using a patent pending opto-mechanical proprietary configuration and activated via an electrical control signal.

All Flyin Optronics` 2×2B Mechanical Fiber Optic Switch(2X2B Optical Switch) support all wavelength at 1260nm~1650nm, it offers ultra-high reliability, low insertion loss, fast switching speed as well as bi-directional performance. The optical switches are widely used for Optical Network, Protection, Transmitter and Receiver Protection, Network Test System and Instrumentations.

Features

Unmatched Low Cost

Low insertion Loss

High Channel Isolation

High Stability, High Reliability

Epoxy-free on Optical Path

Latching and Non-latching

Applications

Optical Network

Protection/Restoration

Optical Singnal Routing

Configurable Optical Add/Drop

Transmitter and receiver protection

Network Test System

Performance Specifications

Parameter

FY-2x2B

Wavelength Range

nm

850

1260~1650

Operating Wavelength

nm

850

1310/1490/1550/1625/1650

Insertion Loss

dB

Typ:0.8 Max:1.2

Typ:0.6 Max:0.8

Return Loss

dB

MM:30 SM:50

Crosstalk

dB

MM:35 SM:55

PDL

dB

0.05

WDL

dB

0.25

TDL

dB

0.25

Repeatability

dB

0.02

Power Supply

V

3.0 or 5.0

Lifetime

Times

107

Switch Time

ms

8

Transmission Power

mW

500

Operating Temperature

-20 to 70

Storage Temperature

-40 to 85

Dimension

mm

(L)28.0×(W)12.6×(H)8.0(±0.2)
