1x2T Mechanical Fiber Optic Switch

Get Latest Price

Payment Type:: T/T

Incoterm:: FOB

Min. Order:: 2 Piece/Pieces

Min. Order:: 2 Piece/Pieces

Delivery Time:: 7 Days

Transportation:: Air

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	shenzhen
Productivity:	2000pcs
Supply Ability:	2000pcs
Payment Type:	T/T
Incoterm:	FOB
Certificate:	CE,ROSE
Transportation:	Air

Product Description

Flyin Optronics` 1x2 Mechanical Optical Switch connects optical channels by redirecting an incoming optical signal into a selected output fiber. This is achieved using a patent pending opto-mechanical proprietary configuration and activated via an electrical control signal.

All Flyin Optronics` 1x2 Mechanical Optical Switch support all wavelength at 1260nm~1650nm, it offers ultra-high reliability, low insertion loss, fast switching speed as well as bi-directional performance. The optical switches are widely used for Optical Network, Protection, Transmitter and Receiver Protection,Network Test System and Instrumentations.

Features

Unmatched Low Cost

Low insertion Loss

High Channel Isolation

High Stability, High Reliability

Epoxy-free on Optical Path

Latching and Non-latching

Applications

Optical Network

Protection/Restoration

Optical Singnal Routing

Configurable Optical Add/Drop

Transmitter and receiver protection

Network Test System

Performance Specifications

Parameter		FY-1×2
Wavelength Range	nm	850	1260~1650
Operating Wavelength	nm	850	1310/1490/1550/1625/1650
Insertion Loss	dB	Typ:0.8 Max:1.2	Typ:0.5 Max:0.8
Return Loss	dB	MM:30 SM:50
Crosstalk	dB	MM:35 SM:55
PDL	dB	0.05
WDL	dB	0.25
TDL	dB	0.25
Repeatability	dB	0.02
Power Supply	V	3.0 or 5.0
Lifetime	Times	10⁷
Switch Time	ms	8
Transmission Power	mW	500
Operating Temperature		-20 to 70
Storage Temperature		-40 to 85
Dimension	mm	(L)27.0×(W)12.6×(H)8.0(±0.2)

Ordering Information

Mode

Wavelength

Voltage Type

Control Model

Fiber Type

Fiber Diameter

Fiber Length

Connector

S=SM

M=MM

85=850nm

13=1310nm

14=1490nm

15=1550nm

62=1625nm

65=1650nm

13/15=1310/1550nm

X=Others

3=3V

5=5V

L=Latching

N=Non- Latching

5=50/125

6=62.5/125

9=9/125

X=Others

25=250um

90=900um

20=2.0mm

30=3.0mm

X=Others

1=1m

2=1.5m

X=Others

0=None

1=FC/PC

2=FC/APC

3=SC/PC

4=SC/APC

5=ST/PC

6=ST/APC

7=LC/PC

8=LC/APC

X=Others
