8+1-CH Coarse Wavelength Division Multiplexer (CWDM Mux/Demux) Module
- Payment Type:
- T/T
- Incoterm:
- FOB
- Min. Order:
- 2 Piece/Pieces
- Min. Order:
- 2 Piece/Pieces
- Delivery Time:
- 7 Days
- Transportation:
- Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | shenzhen |
|---|---|
| Productivity: | 2000pcs |
| Supply Ability: | 2000pcs |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Certificate: | CE,ROSE |
| Transportation: | Air |
Features
Low Insertion Loss
Wide pass band
High Channel Isolation
High Stability and reliability
Epoxy-free on Optical Path
Access Network
Applications
Line Monitoring
WDM Network
Telecommunication
Cellular Application
Fiber Optical amplifier
Acess Network
Performance Specifications for 8+1-CH CWDM Module
|
Parameters |
8+1-CH Mux |
8+1-CH Demux |
|
|
Channel Wavelength (nm) |
1270-1610 or 1271-1611 |
||
|
Center Wavelength Accuracy (nm) |
0.05 |
||
|
Channel Spacing (GHz) |
20nm |
||
|
Channel Passband (-0.5dB bandwidth (nm) |
13 |
||
|
Insertion Loss (dB) (Without skip component) |
2.8 |
||
|
Insertion Loss (dB) (With skip component) |
2.0 |
||
|
Channel Uniformity (dB) |
0.6 |
||
|
Channel Ripple (dB) |
0.3 |
||
|
Isolation (dB) |
Adjacent |
30 |
|
|
Non-adjacent |
40 |
||
|
Express Port |
12 |
||
|
Insertion Loss Temperature Sensitivity (dB/ ) |
0.005 |
||
|
Wavelength Temperature Shifting (nm/ ) |
0.002 |
||
|
Polarization Dependent Loss (dB) |
0.1 |
||
|
Polarization Mode Dispersion (ps) |
0.1 |
||
|
Return Loss (dB) |
50 |
||
|
Directivity |
45 |
||
|
Max Power Handling (mW) |
300 |
||
|
Operating Temperature () |
-5 to +75 |
||
|
Storage Temperature () |
-40 to +85 |
||
|
Package Dimension (mm) |
L100 X W80 X 10 |
||
Note: All parameters are for device without connectors.
