82keys Red Backlit Black Metal Keyboard With Touchpad & Numeric Keypad
Special Features:
1. 82 keys compact format IP65 dynamic rated
2. Vandal proof stainless steel industrial kiosk keyboard with touchpad,
3. With numeric keypad.
4. With IP65 dynamic sealed & ruggedized tough touchpad
5. High quality scratch-proof durable black titanium electroplated on the top stainless steel plate and all keys
6. Panel mounting solution.
7. With IP65 dynamic sealed & ruggedized tough touchpad for fast and accurate cursor position,
8. High quality scratch-proof durable black titanium electroplated on the top stainless steel plate and all keys
9. With adjustable industrial backlight included
Applications:
This durable and black Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:
|
MECHANICAL DATA |
|
|
Key |
82 keys, super quality brushed stainless steel |
|
Key top style |
Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available |
|
Key Size |
14.0mm x 14.0mm for normal keys, |
|
Key travel |
2.0mm |
|
Switch life |
more than 10 million of operations |
|
Actuation Force |
0.6N +/-0.1N for key 14.0mm x 14.0mm (pressure point) |
|
Front Plate |
1.5mm thickness super quality brushed stainless steel |
|
Back Plate |
3.0mm thickness brushed and oxidized aluminium |
|
Lettering |
Sunk laser legends & characters in high quality ink |
|
Actuator/keys materials |
stainless steel |
|
G.W. |
2.30KGs |
|
Dimension |
400.0mm x 124.0mm (top panel) |
|
ELECTRICAL DATA |
|
|
Supply Voltage |
+5V DC +/-5% |
|
Current Rating |
appr. 20mA |
|
EMC Standard: |
It is compliance with the council IEC 61000-4-2:2008; |
|
EMI: |
EN 55022: 2010 |
|
EMS: |
EN 55024:2010 |
|
Lifespan |
> 5 years |
|
Switch Contact Material: |
Carbon-on-Gold key switch technology PCB. |
|
Interface: |
PS2, USB available. |
|
OS: |
All windows, Linux, Unix, Mac OSX |
|
ENVIRONMENTAL ADAPTABILITY |
|
|
Operating temperature |
-20oC to +60oC |
|
Storage temperature |
-30oC to +70oC |
|
Operating RH |
30-90% |
|
Atmospheric pressure |
60-106Kpa |
|
Saline mist |
96 hours, IEC 60512-6 |
|
Damp heat test at + 40oC |
21 days, IEC 60512-6 |
|
Dry heat test at + 85oC |
10 days, IEC 60512-6 |
|
RELIABILITY |
|
|
Certification |
RoHS Compliant, CE and FCC,IP65,ESD |
|
Protection Level |
IP65(front panel) |
|
Vandal resistant |
IK09 |
|
Key Lifespan |
>10 million actuations |
|
MTBF |
>50000H |
|
MTTR |
<30min |
