CE Permanent Magnet Alternator Tabular Turbine, Micro Hydro
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|
Product Description
Product Description
CE Permanent Magnet Alternator Tabular Turbine, Micro Hydro Generator, High Efficiency
Tabular Turbine
1. CE certificate
2. Excellant quality
3. Easy installation
4. Wide range
A mini extension shaft tabular turbine is made of water chamber, runner, Distributorand draft tube, which suits to low water head and large water flow, and capacity from 0.8Kw to 30Kw.
| No. | Generator Model |
Fall (m) |
Flow L/S |
Permanent magnet alternator (W) |
Speed (r/min) |
G. W (kg) |
Packing size (cm) |
| 1 | GD-LZ-20-3KW | 4 | 136 | 3000 | 1500 | 300 | 130× 65× 88 |
| 2 | GD-LZ-20-5KW | 6 | 151 | 5000 | 1500 | ||
| 3 | GD-LZ-20-6KW | 7 | 156 | 6000 | 1500 | ||
| 4 | GD-LZ-20-8KW | 9 | 161 | 8000 | 1500 | ||
| 5 | GD-LZ-20-10KW | 11 | 165 | 10000 | 1500 | ||
| 6 | GD-LZ-13-1.5KW | 5 | 60 | 1500 | 1500 | ||
| 7 | GD-LZ-12-3.0KW | 11 | 45 | 3000 | 1500 | 140 | 142× 65× 60 |
