Vertical Kaplan Hydro Turbine 100KW - 30MW For Power Statio

Vertical Kaplan Hydro Turbine 100KW - 30MW For Power Station

The Kaplan Hydro Turbinecan be classified into two forms : fixed blades and adjustable blades.

1.Fixed blades: generally applicable to power station that is small and medium capacity, small variation of head

and power.

Features:

① Simple structure

②When deviate from the design condition, the efficiency will fell sharply

2.Adjustable blades:generally applicable to power station that is large and medium capacity, large variation of head

and power.

Features:

① combined automatically adjusted blades with automatically adjusted guide vane to achieve efficiency over a wide range

of flow and water level,Wide range of high efficiency zone.

②Because of the need to rotating blades operating mechanism, the structure is more complex

Fuchun Industry Development Co., ltd Shenzhen is an experienced manufacture and engineering Company in

small scale hydro power equipment ( 100Kw to 50Mw). We have over own factory with over 50 year experiences,

we produce covers Francis, Pelton, Turgo, Kaplan, and also Tubular type which could suit to different water head

condition from 2meter to 1200 meters. As Generator manufacture more than 50 years experience, we

manufacture vertical and horizontal low speed and high speed types which could be equip with different type of

hydro tribunes. The high quality hydro turbine and generator are wildly used in all parts of China, and foreign

countries such as Italy, UK, Albania, Gorgia, Pakistan,Vietnam, and south America countries,South Africa

Countries.

Fuchun has a experienced and professional team to work for site survey, civil work design and power system

design. Also there is a strong after sale service to serve at different projects in the world.
