Multifunction D36VR Underwater Video Lights Max 5200 Lumens with Red / Purple / UV Light

PRODUCT SPECIFICATIONS:

Model	D36VR R multifunction underwater photographing Light
Bulb	White CREE XM-L2 U2 LED 8 (max 5200 Lumens); Red CREE XP-E N3 LED4 wavelength 620 nm (max 400 Lumens); Purple LED 2 wavelength 410nm (max 6W); UV LED2 wavelength 365nm (max 6W)
Control	Switch 1: Red> Purple> UV> off Switch 2: White high> White medium >White low> off The two switches can be operated separately or simultaneously.
Runtime	White High Mode: 1.5H; White Medium Mode: 3.0H; White Low Mode: 4.0H Red Light: 4.0H; Purple Light: 5.0H; UV light: 5.0H
Color temperature	5000K (white light)
Reflector	No hotspot design, no reflector
Lens	4mm Polycarbonate Board
Body material	Durable aircraft-grade aluminum
Angle of light beam	120°
Surface treatment	Premium Type III hard-anodizing
Color	Black
Battery	18650 rechargeable Li- ion battery *4
Battery Indicator	100%-50%: Green; 50%-30%: Yellow; 30%-10%: Red; Below 10%: Red Flashing; Below 5%: switch off
Circuit Protection	With battery over-discharging protection, polarity reversing protection
Operation voltage	2.8V to 4.2
Waterproof	100 meters underwater
Dimensions	140.9mm (length)* 62.6mm (dia. of head)
Weight	490 grams (without battery); 682.4 grams (with battery)
Underwater Weight	330 grams (with battery)
Impact resistance	1.5M.
Explosion Protection	with gas release valves

BATTERY INSTALLATION

Remove the tail by turning counter-clockwise.
Remove used batteries and replace with fresh batteries as shown by the polarity stickers.
Mount the tail by turning clockwise.

BATTERY CHARGING

Plug the charger in the wall power socket, the indicator light is green in the free-load status.
Put the battery in the slot of the charger.
The indicator light is red if the battery is not fully charged; it will turn green after fully charged.
Take out the fully charged battery and use them in the diving light.

ON/OFF

Push the button switch to turn it ON.

MODES CHANGING

Successive push the switch 1 ON-OFF within two seconds to cycle through Red, Purple, UV Light, OFF;
Successive push the switch 2 ON-OFF within two seconds to cycle through High, Medium, Low (white light), OFF.

SCUBA DIVING APPLICATION

Check closely for cuts, scratches, or an otherwise damaged O-ring or mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the O-ring sealing surfaces.

KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.

CAUTION

If the light is not to be used for some time, remove the batteries to prevent possible leakage or corrosion. Please remove the batteries during transportation to prevent it from misoperation.

If the switch gets stuck, please put some washing-up liquid in the slot of the switch and push the switch back and forward several times till it move smoothly again, then clean the light in the fresh water.

WARRANTY RETURN POLICY

Please contact your local distributor or retailer for information on how to handle your warranty items.

REPLACEMENT PARTS

CAT# DESCRIPTION

D368 O-ring

D369 Lens
