D10S 860 Lumens Backup LED Scuba Diving Lights with Glossy

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China

Product Description

D10S Aluminum 860 Lumens LED Scuba Diving Lights Backup Dive Light

PRODUCT SPECIFICATIONS

Model	D10S Diving Light
Bulb	Cree XM-L U2 (Max 860 lumens)
Color temperature	6500 K
Output Function	High> Off
Runtime	70 min.
Reflector	Glossy Aluminum reflector
Body material	Durable aircraft-grade aluminum
Angle of light beam	8°
Surface treatment	Premium Type III hard-anodizing
Color	Black
Battery	18650 Li- ion battery * 1
Circuit Protection	With battery over-discharging protection, polarity reversing protection
Operation voltage	3.0V to 4.5V
Low voltage alarm	flash 3 times when the voltage is below 3V and flash 3 times again in 5 second, then change to 10% brightness till switch off when the voltage is below 2.8V
Waterproof	100 meters underwater
Dimensions	145(length)24(dia. of end)29mm (dia. of head)
Weight	115grams (without battery); 165 grams (with battery)
Underwater Weight	135 grams (with battery)
Impact resistance	1.5M

BATTERY INSTALLATION

Separate the light head and body by turning counter-clockwise.
Remove used batteries and replace with fresh batteries as shown by the polarity stickers.
Mount the light head on the body by turning clockwise.

BATTERY CHARGING

Plug the charger in the wall power socket, the indicator light is green in the free-load status.
Put the battery in the slot of the charger.
The indicator light is red if the battery is not fully charged; it will turn green after fully charged.
Take out the fully charged battery and use them in the diving light.

ON/OFF

Push the switch forward to turn the light on.

Push the switch forward again to turn the light off.

SCUBA DIVING APPLICATION

Check closely for cuts, scratches, or an otherwise damaged o-ring or mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the o-ring sealing surfaces.

KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.

CAUTION

If the light is not to be used for some time, remove the batteries to prevent possible leakage or corrosion. Please remove the batteries during transportation to prevent it from misoperation.

WARRANTY RETURN POLICY

Please contact your local distributor or retailer for information on how to handle your warranty items.

REPLACEMENT PARTS

CAT# DESCRIPTION

D10S8 O-ring

D10S9 Lens
