Magnetic RJ45, 10/100M Tab Down SMT RJ45 Network Connector
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|
Magnetic RJ45, 10/100M Tab Down SMT RJ45 Network Connector with filter for Internet Set-top Box Applications
Part Number:KRJ-SM017NL
Specifications:
.Turn Ratio :1CT:1CT±3%
.OCL:350uH@100KHZ 100Mv 8mA DC
.Contacts:0.35mm thick phos bronze plated with 6u’gold in contact are
.Housing Material:PBT Black
.Operating temperature rang :0℃ to +70℃
.Insertion Loss :1-100MHZ -1.0dBmax
.Rturn Loss : 1-30MHZ -16.0dBmin
30-60MHZ -14.0dBmin
60-80MHZ -10.0dBmin
.Cross Talk :1-30MHZ -40.0dBmin
30-60MHZ -35.0dBmin
60-80MHZ -30.0dBmin
.CMR:1-100MHZ -35.0dBmin
.Hi-Pot:1500V AC 6S 1mA
Schematic:
Description:
RJ45 ,in order to keep good touch between gold finger and crystal head,should paint the gold on the surface,there is 6u,15u,30,50u,usually use 6u,according to customer’s request and cost to proceed, gold finger insert and pull life should be 750 times above.
- 10/100Base-Tx RJ45 single port 1X1 Vertical without LED with SMD
- Single port 1X1 Tab-Down RJ45 with internal magnetics
- Internal magnetics are 100% electrically tested for HI-POT and functionality
- Suitable for CAT5&6 fast Ethernet Cable or better UTP
- 350uHminimum OCL with 8mA bias current
- High performance for maximum EMI suppression
- Minimum 1500Vrms isolation per IEEE 802.3 requirement
- ROHS-6 peak wave solder temperature rating 260℃
- Operating temperarure range :0℃ to +70℃
- Storage temperature range :-40℃ to +85℃
- Number of positions:8
- Number of contacts loaded:8
- Shield:YES
- Rohs compliant
- Length:21.3mm
- LEDS:NO
- EMI fingers:NO
- Usage:KRJ-SM017NL
Mechanical Dimensions:(Unit:mm)
Front view
SIDE VIEW
.XX Tolerance:+/-0.25
.XXX Tolerance:+/-0.13
PCB Layout Mouting Hole:(Unit:mm)
.XX Tolerance:+/-0.25
.XXX Tolerance:+/-0.13
Applications:
• Integrated RJ45 connector main used to :
• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,
internet set-top box,internet camera,net bridge,computer,telecommunication,MODEM,HomePNA,DSL/ADSL and so on.
Competitive Advantage:
Keyouda has various types of appearance and many kinds of internal schematic products,high quality, customer firstly ,
100% test, 0 defect, short lead time are our best advantages
