Wireless wifi baby monitor with MJPEG/ H.264 , Pan/ Tilt, TF card

Catalogue

   Type

Parameters

Features

View by phone

Support monitoring via mobile devices on line(such as iOS,Android OS,Symbian OS,WindowsPhone7) Support Mac and windows pc

Mobile Platform

No need to install software, Multi-screen monitoring and managing by mobile phone, alarming, viewing.

View on PC

Internet Explorer 6.0 or higher version,firefox,chrome, safri

Monitor Advantage

Support  IPhone,Android,Computer monitor. Miscrosoft certification plugin, no virus risk.

Sever cluster

Using Amazon Cloud P2P servier cluster, Intelligent application and super stable

UID Technology

UID scan technology applied, easy to operate, and highly confidential.

Easy operation

Plug & Play, P2P technology, penetration degree can be 99%, applicable toany complex network surroundings. Easy operation 1. plug the cable and power line, 2.install computer software, scan code to add camera.

lLocal Memory

Support 32G TF Cards

Super Client

1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm

System

Operation system

Embedded Linux OS

System security

Supports three-level account, password, user multi-level authority management

DDNS

Provide DDNS for free ,like demo.gocam.so

Collection

Image sensor

1/3 inch 0.3 Megapixel line by line CMOS sensor

SNR

≥50dB

Minimum Illumination

0.3Lux

3A

Auto White Balance, Auto Exposure, Automatic Gain

Lens

Standard 3.6mm

Resolution

VGA(640×480)/QVGA(320×240)

Maximum frame rate

25fps

Bit Rate

32Kbps~4Mbps can be set

Adjustment

light intensity,contrast ratio,saturation level are adjustable.

Nightvision

IR-CUT

Built in IRCUT,no color cast in day, clearer images at night

Effect

10 Φ5mm LEDs   IR Distance 10 m

Audio

Encode formats

ADPCM

Input

Built in Microphone

Output

one channel linear output, normal connector Of 3.5mm

View by SD Card

Remote browsing, download of content from 32G tf card

Network

Socket

RJ-45   10/100Mb   self-adaptable Ethernet slot

Protocol

TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,PPPoE , etc

WIFI

WIFI 802.11 b/g/n

Visitors Online

Support 8 visitors viewing on line

P/T

Control Method

Pan 270°,Tilt 90°(speed can be set)Highest speed 70°/s

Alarm

Alarm Detection

Support motion detecting / 1 way input triggered

Alarm action

1 way output/E-mail pictures /upload video by FTP/messages alarm(coordinate to server)

Physical index

Power

DC 5V2A

Comsumption

<6W

Temperature

Humidity

10%~85%

Weight

Gross 656g  (Note in kind prevail)

Package size

200*120*180mm (L*W*H)
