240W24V Switching Power Supply
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| White | white/green |
|---|---|
| Output Frequency | 47-63HZ |
| Output Power | 201-300W |
| Output Voltage | 24V |
| Input Voltage | 220V |
| Output Type | Other |
| Output Current | 10A |
Detail Description
8.1 AC input voltage range: AC90-132V or AC180-264V (selected by switch)
8.2 AC input Frequency: between AC47Hz and 63Hz
8.3 AC input current: AC 4.5 A under 115V or AC 2A under 230V
8.4 inrush current: AC 35A under115V or AC 60A under 230V (cold-state started)
8.5 AC Leakage current: below AC 0.5mA under 240V
8.6 Adjustable range for DC output voltage: ±10% (based upon the input voltage)
8.7 Overload protection: The output can be cut off when it’s overloaded by 5-50% and revert automatically.
8.8 Overvoltage protection: The output can be cut off when it’s 115-135% of the rated voltage.
8.9 Time to start, rise and hold up: corresponding to 200 ms, 100 ms and 20ms
8.10 Voltage-withstanding characteristic: 1min under AC 1.5KV; IP- sheath: 1min under AC 1.5KV; OP- sheath: 1min under AC 0.5KV
8.11 Working temperature: between -10℃ and 60℃
8.12 Working humidity: between RH 20% and 90% 8.13 Safety characteristic: in accordance with GB4943, UL60950 and EN60950
8.13 EMC characteristic: in accordance with GB9254 and NE55022
8.14 Net weight: 700g
8.2 AC input Frequency: between AC47Hz and 63Hz
8.3 AC input current: AC 4.5 A under 115V or AC 2A under 230V
8.4 inrush current: AC 35A under115V or AC 60A under 230V (cold-state started)
8.5 AC Leakage current: below AC 0.5mA under 240V
8.6 Adjustable range for DC output voltage: ±10% (based upon the input voltage)
8.7 Overload protection: The output can be cut off when it’s overloaded by 5-50% and revert automatically.
8.8 Overvoltage protection: The output can be cut off when it’s 115-135% of the rated voltage.
8.9 Time to start, rise and hold up: corresponding to 200 ms, 100 ms and 20ms
8.10 Voltage-withstanding characteristic: 1min under AC 1.5KV; IP- sheath: 1min under AC 1.5KV; OP- sheath: 1min under AC 0.5KV
8.11 Working temperature: between -10℃ and 60℃
8.12 Working humidity: between RH 20% and 90% 8.13 Safety characteristic: in accordance with GB4943, UL60950 and EN60950
8.13 EMC characteristic: in accordance with GB9254 and NE55022
8.14 Net weight: 700g
Additional Information
| Payment Terms | T/T |
|---|---|
| Minimum Order | 1000pcs |
| Lead Time / Delivery Time | 7 Day(s) |
| Sample Available | YES |
| Delivery Details | If the quantity is large, the delivery date should be delayed reasonably. If normal, within 7 days. |
| FOB Port | Shenzhen,Yantian |
| Loading Info | by sea, but it can also be decided by the customer. |
| Packing Info | Each piece is packed in a small carton, and then a certain number of pieces are contained in a big carton. |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
