Plastic Switch with Yellow Button

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

plastic switch with yellow button	plastic switch
with yellow button	Membrane keypads with FPC

Detail Description

1. Electronic characteristics
• Circuit rating: 35V (DC), 100mA, 1W
• Contact resistance: 10Ω--500Ω (According the trace length and materials to comfirm)
• Insulation resistance:> 100MΩ 250V DC
• Contact bounce: ≤ 5ms
• Dielectric withstand:250VRms (50-60Hz 1min)
• Life expectancy: flat type ≥ 5 million times
• tactile type: ≥ 1 million times
2. Mechanical Properties Actuation force
• flat type 57-284g (2-10 Oz)
• tactile type 170-397g (6-14 Oz)
• Switch stroke: flat type 0.1-0.5mm
• tactile type 0.6-1.5mm
3. Environmental parameters
• Operating Temperature: -40 C- +80 C
• Storage temperature: -40 C - +85 C
• Humidity: 40C , 90% -95%, 240 hours

Additional Information

Payment Terms	T/T
Minimum Order	500PCS
Sample Available	YES
FOB Port	Shenzhen
Target Market(s)	North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East
