Cable Cat 6 FTP stranded 23 AWG PVC

        Cable Cat 6 FTP stranded 23 AWG PVC
                       Cable Cat 6 FTP stranded 23 AWG PVC
Conductor Dimension: 0.52~0.56 ±0.02mm

Conductor Material: CU/CCC/CCA /CCC+CCA/CCA+CCS

Insulation: 1.0mm HD-PE (High density polyethylene)

Number of Twisted Pair: 4P

Jacket: PVC (Polyvinyl-Chloride)

     LSOH (Low Smoke Zero Halogen)

The external cable diameter: 6.5~6.8mm

Color: different color is available

Operating temperature: -20 ° C - +75 ° C

UTP unshielding: Plastic Seperator and Ripcord

FTP shielding: Plastic Seperator+Polyester+Al Foil+Ripcord

SFTP shielding: Plastic Seperator ,Polyester+Al Foil+Ripcord+Braiding


Introduction:

CAT6 is an Ethernet cable standard defined by the Electronic Industries Association and Telecommunications Industry Association (commonly known as EIA/TIA). CAT6 is the sixth generation of twisted pair Ethernet cabling.

CAT6 cable contains four pairs of copper wire like the previous generation CAT5. Unlike CAT5, however, CAT6 fully utilizes all four pairs. CAT6 supports Gigabit Ethernet speeds up to 1 gigabit per second (Gbps) and supports communications at more than twice the speed of CAT5e, the other popular standard for Gigabit Ethernet cabling.

Cross-shaped wire as the filler enhance article proximal crosstalk (NEXT) and impedance performance and strengthen the bandwidth and SNR surplus
