1PC Class 150 Reduced Bore Floating Ball Valve
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|
REDUCED PORT
MATERIAL: CF8M / WCB
AVAILABLE SIZE: 1/2"-10" (DN15-DN250)
WORKING PRESSURE: ClASS 150 Lbs
Specifications:
1-PC Ball Valve-
REDUCED -PORT
INVESTMENT CASTING
MATERIAL:- CF8M-/ WCB
BLOWOUT PROOF STEM--
AVAILABLE SIZE: 1/2"-10" (DN15-DN250)
WORKING PRESSURE:- ClASS 150 Lbs
WORKING TEMPERATURE: <180°( PPL < 300°C )
-
Flang Standard : ANSI B 16.5
Face to Face : ANSI B 16.10
Fire-safe : API 607
Check and Test : ANSI B 16.34- or API 598
Suitable Medium : Water , Gas-, Oil , Nitric Acid , Acetic Acid etc.
Fire-safe and Anti-static device available
-
Industrial ball valves are available in sizes 1/4" - 12" and in a variety of body materials including bronze, carbon steel, stainless steel, monel and alloy 20. End connections include FNPT, socket weld, butt weld and ANSI 150 & 300 flanged. Body styles include one-piece, two-piece, three-piece. A wide variety of trim materials and seating options are available. Locking, oval & extended handles are available. Special preparations such as fire-safe,chlorinr prep and cleaned for oxygen service are also available.
