UL 6AWG 750V 16A terminal block connectors Nylon PA66 with
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|
Product Description
Product Description
UL 6AWG 750V 16A terminal block connectors Nylon PA66 with Steel Screw
1.terminal block
2.Pitch:15mm H=29.5
3.Screw:M4,Steel,Zinc plated
4.Wire Protector :Brass,Tin plated
5.STDcolor:Orange/Gery
2.Pitch:15mm H=29.5
3.Screw:M4,Steel,Zinc plated
4.Wire Protector :Brass,Tin plated
5.STDcolor:Orange/Gery
terminal block, GSO100, have been approved by CE IMQ ROHS VDE and UL. The details are as following:
| Pitch | 15mm H=29.5 |
| Approval | Applying UL VDE |
| Rated voltage | 750V |
| Rated current | 16A |
| Wire range | 6-22AWG |
| Torque | 0.4N.m |
| Screw | M4,Steel,Zinc plated |
| Insulating material | Nylon PA66 UL94V-0 |
| Temperature range | -40/+120 |
| Terminal | Brass,Ni plated |
| Wire Protector | Brass,Tin plated |
| STD color | Orange/Gery |
