SMD2121 1R1G1B Mobile Rental LED Display Panel For Car Show
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | shenzhen |
|---|
SMD2121 1R1G1B Mobile Rental LED Display Panel For Car Shows , 4.81 Pixel 1600 cd/m2
Quick Detail:
1) Stable quality:Opto + Silan chipset;
2) High brightness:1400 ~1600nits;
3) Scan driver:1/13 current;
4) Cabinet size(L*W):500*500mm;
Description:
P4.81 Die-casting Indoor Full Color LED Display Screen
4.81mm pixel pitch,1R1G1B,43264 dots/sqm,P4.81 Die-casting Indoor Full Color LED Display Screen creates comfortable brightness and energy saving,display variable video resources,animations,messages to attract attention. We can see P4.81 Die-casting Indoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Applications Occasions:
Sports,advertising,traffic,entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc
Specifications:
P4.81mm Die-casting Indoor Full Color LED Display Screen:
|
Pixel configuration |
SMD2121 1R1G1B 3 in 1 Black LED |
|
|
LEDs configuration |
Red:wave length: 615~625nm;130mcd |
|
|
Pixel pitch(mm) |
4.81 |
|
|
Pixel density(dots/sqm) |
43264 |
|
|
Calibrated brightness(cd/sqm,nit) |
1600 nits(adjustable) |
|
|
Calibrated brightness proportion ratio |
R:G:B = 3:6:1 |
|
|
Contrast ratio |
4,500:1 |
|
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
|
View angle(degree)(50% brightness) |
V140/H140 |
|
|
Color capability |
4.4 trillion |
|
|
Refresh rate(Hz) |
>800 Hz |
|
|
Frame frequency(Hz) |
>60 Hz |
|
|
Interface port |
DVI interface(DVI connector) |
|
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
|
LED Drive |
Constant-current drive |
|
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
|
Signal transmission direction |
Horizontal |
|
|
Operating temperature(Celsius degree) |
-20 ~ 60 |
|
|
Storage temperature(Celsius degree) |
-30 ~ 80 |
|
|
Operation humidity(RH) |
10-95% |
|
|
Operation humidity(RH) |
10-99% |
|
|
Servicice |
Front and back service optional |
|
|
Control mode |
Synchronous & asynchronous available |
|
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
|
Power |
120/240 VAC single phase(50-60Hz) |
|
|
Maximum power consumption(W/sqm) |
1200 |
|
|
Average power consumption(W/sqm) |
400 |
|
|
Screen operation mode(scan/static) |
1/13 |
|
|
Cabinet configuration |
Length |
104 |
|
Height |
104 |
|
|
Cabinet dimensions(mm) |
Length |
500 |
|
Height |
500 |
|
|
Width |
85 |
|
|
Recommend Optimal Viewing Distance: Minimum & Maximum |
Min |
5 |
|
Max |
100 |
|
|
Aspect Ratio(L:H) |
4:3 or 16:9 |
|
|
Packaging configuration |
5 standard cabinets in a flight case |
|
|
Packing material |
flight case |
|
|
Packing weight(KG) |
net |
8KG/cabinet |
|
gross |
9KG/cabinet |
|
LED Display Screen Installation Structure:
Hanging ,floor type,push-in- type,wall mounting type,brace type,pillar base...
Competitive Advantages:
1) Stable quality and fast Response;
2) Short delivery,effective production;
3) Sample order,trial order be acceptable;
4) Good communication;
5) 2 years warranty;
