Free Staning Slim Self Service Card Dispenser Touch Panel Kiosk With HD Camera
Quick Detail:
- Self service security payment terminal for multi payment solutions via cash, coins, bank card or check etc…
- Interactive touch technology;
- Unattended, Anti vandalism, strong metal or stainless steel mechanism integrated with smart electronic alarming and server system.
- More than 15 years manufacturing experiences and products applied /placed more than 180 countries
- Upgradable functions available
- Flexible Modification to fit customers requirements
- In-door or out-door optional
Specifications:
|
Airport Kiosk: Check-in / Bag drop-off |
|
|
Components |
Specification |
|
Computer |
Industrial PC or Standard PC upon request Supports serial ports and USB ports for satisfying different devices connection Industrial Power supply; Graphics integrated Wireless or Ethernet connection available. |
|
Monitor |
A+ class TFT-LCD Monitor: 15”, 17”, 19”, 21”, 22”, or bigger size or smaller size available. |
|
Touch screen |
SAW touch /Infrared touch / Capacitive touch/ 5 wire resistive touch against different kiosk project requirements. |
|
Passport Scanner |
Passport and barcode reader; Full/half page OCR and full text scanner with RF option for e-passport |
|
Barcode Scanner |
1D & 2D barcode imager read barcodes from paper or mobile devices; 2D barcodes: PDF417, Datamatrix, Aztec and QR code 1D barcodes: Code128, Code39, Interleaved 2 of 5, UCP/EAN, Codabar |
|
Fingerprint Reader |
Fingerprint reader is optional for passenger enrolment, authentication, and identification |
|
Card Reader |
Hybrid ISO 1, 2, and 3 track magnetic and smart card reader; Manual or motorized insertion; RF contactless card reader optional |
|
Payment Module |
EMV certified Chip & PIN PCI PED 3x compliance for overweight charge |
|
Boarding Pass Printer |
200/300dpi thermal direct 1D/2D barcoded printing; Width: from 20mm to 216mm; Automatic cutter available Printing speed: >150mm/sec; RS232 or USB interface |
|
Bag Tag Printer |
200dpi thermal direct 1D/2D barcoded printing; Width: from 20mm to 54mm; Printing speed: > 150mm/sec; RS232 or USB interface |
|
Receipt Printer |
Thermal Printer : Width 80mm~210mm; black mark sensor; full/half cutter |
|
Wireless Connection |
Wi-Fi/ GPRS modem/ 3G device optional |
|
Camera |
HD camera |
|
Speaker |
Multimedia: Left-right bi-channel amplified output |
|
Enclosure |
Moistureproof, Antirust, Anti-acid, Anti-dust, Static free High quality steel sheet made enclosure/ stainless steel / Aluminum available. Powder coated finish; color to be negotiated with customer. |
|
OS& Drivers |
Windows XP/Window7/Unix/Linux OS available; All related hardware drivers/SDK available for the software development/integration |
|
Packing |
Bubble Foam, carton, wooden case |
|
Other Optional : UPS, Video Camera, Alarm System, Barcode Scanner, Track Ball, Photo Printer, Cash Acceptor, Card Dispenser, Check Acceptor, Infrared, Bluetooth, PSAM Card, etc. |
|
Description:
KMY8500 series kiosks are free-standing, slim and most important with elegant curves. Simple, easy-going, eyeball attracting makes it’s the best choice for overall indoor kiosk applications. And as one of our hottest sales, the sleek, streamlined design and durable construction make this series of kiosks the ideal choice for most self-service kiosk application.
The kiosks can be used as bill payment, public internet access, information check, ticketing, music download, order entry, and many others in Retail, Hotel, Finance, Banking and Insurance, Gaming and Gambling, Travel and Tourism, Airport, Queue, etc.
Warranty Information:
- 1 Year warranty
- Terms & conditions apply
- Refer to standard warranty policy for details
