Product Description

Description:

The HDMICAT60RX&TX extender use double cat-5E or cat-6 (recommended) cables up to 60 metres instead of HDMI cable to transmit high definition signal, for cutting down cost
Supports HDMI 1.3V signal (10.2Gbps/deep color 36-bit/xv-YCC/1,080P, 24fps/DTS-HD) for 60m transmit via Cat 7 LAN cable
Supports HDMI 1.2V signal (5.1Gbps/24-bit full-HD 1,080P, 24fps/DTS/AC3/LPCM) for 60m transmit via Cat5e/6 LAN cable
HDCP 1.2V, supports 1,080P/1,080i/720P/576P/576i/480P/480i
Supports video color: 36-bit (Cat 7), 24-bit (Cat 6), one meter is 3.3ft
Up to 60m for full-HD 1,080P HDMI transmit support with STP or FTP Cat5e/6, at least 60m for HDMI 1.3V transmit support with cat 7

Features:

Supports HDMI 1.2 protocol
HDCP 1.2 protocol compliant
Support video input: 24/50/60fps/1,080p/1080i/720p/576p/576i/480p/480i
Signal transmission: double Cat5e or 6 (recommended) cables up to 60 meters instead of HDMI cables are connected between TX and RX extender
Supports video output: 24/50/60fps/1,080p/1080i/720p/576p/576i/480p/480i
Supports CEC
Audio format supports: DTS-HD/Dolby-True HD/LPCM7.1/DTS/Dolby-AC3/DSD
LED indication: when power is supplied or device is working, LED relative to is light
Supports up to 20 meters AWG26 cable length between extender and source and sink device
No loss of quality
Installs in minutes
Need 5V DC/2A power supply

Accessories:

5V power adapter
One piece of user’s manual

Package details:

20 pieces/carton, 10kg/carton, box size: 424*312*300mm

The HDMICAT60RX&TX extender use double cat-5E or cat-6 (recommended) cables up to 60 metres instead of HDMI cable to transmit high definition signal, for cutting down cost

Supports HDMI 1.3V signal (10.2Gbps/deep color 36-bit/xv-YCC/1,080P, 24fps/DTS-HD) for 60m transmit via Cat 7 LAN cable

Supports HDMI 1.2V signal (5.1Gbps/24-bit full-HD 1,080P, 24fps/DTS/AC3/LPCM) for 60m transmit via Cat5e/6 LAN cable

HDCP 1.2V, supports 1,080P/1,080i/720P/576P/576i/480P/480i

Supports video color: 36-bit (Cat 7), 24-bit (Cat 6), one meter is 3.3ft

Up to 60m for full-HD 1,080P HDMI transmit support with STP or FTP Cat5e/6, at least 60m for HDMI 1.3V transmit support with cat 7

Supports HDMI 1.2 protocol

HDCP 1.2 protocol compliant

Support video input: 24/50/60fps/1,080p/1080i/720p/576p/576i/480p/480i

Signal transmission: double Cat5e or 6 (recommended) cables up to 60 meters instead of HDMI cables are connected between TX and RX extender

Supports video output: 24/50/60fps/1,080p/1080i/720p/576p/576i/480p/480i

Supports CEC

Audio format supports: DTS-HD/Dolby-True HD/LPCM7.1/DTS/Dolby-AC3/DSD

LED indication: when power is supplied or device is working, LED relative to is light

Supports up to 20 meters AWG26 cable length between extender and source and sink device

No loss of quality

Installs in minutes

Need 5V DC/2A power supply

5V power adapter

One piece of user’s manual

20 pieces/carton, 10kg/carton, box size: 424*312*300mm
