5.6-inch Digital Car Monitor for Buses
  • 5.6-inch Digital Car Monitor for Buses
5.6-inch Digital Car Monitor for Buses

5.6-inch Digital Car Monitor for Buses

Get Latest Price
Payment Type:
T/T in Advance
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T in Advance
Product Description
Product Description
  • Specifications:
    • Dimensions: 5.6-inch monitor
    • TV system: NTSC/PAL
    • Resolution: 640 x 3 x (RGB) x 480 pixels
    • Brightness: 250cd/m²
    • Contrast: 500:1
    • Lattice distance (H x V): 0.0588 x 0.1764P
    • Aspect ratio: 4:3
    • Viewing angle:
      • Up: 50°
      • Down: 70°
      • R/L: 70°
    • Rating: 20,000 hours
  • Features:
    • Products featured function
    • Multiple menu languages: English, Dutch, French, Portuguese, Spanish, Russian, German
    • With remote control
    • Monitors can be optional with loudspeaker or not, users can adjust sound on the control panel or remote control
    • Screen display mode can be switched the day mode and night mode by pressing button
    • Supports 2 cameras video simultaneous input
    • Supports 2 cameras audio simultaneous input
    • Normal or mirrored picture can be switched separately on each camera
    • Separate trigger control wire on each camera
    • Monitor will automatic switch-over the image to the corresponding triggered camera and back to the original mode when the trigger stops
    • The trigger delay time can be adjusted (0-4 seconds) on each camera
    • In standby mode, monitor will turn on automatically when triggered and will switch to the corresponding trigger camera image
  • Specifications:
    • Working voltage: 12-32V
    • Working current: 800mA (with in 2 cameras)
    • Self-protect of the DC voltage at the short-circuit
    • Operating temperature: -10-65°C
    • Storage temperature: -30-80°C
    • Bracket option: U/S-shape
    • Outer dimensions: 154 x 123 x 30mm
  • Dimensions: 5.6-inch monitor
  • TV system: NTSC/PAL
  • Resolution: 640 x 3 x (RGB) x 480 pixels
  • Brightness: 250cd/m²
  • Contrast: 500:1
  • Lattice distance (H x V): 0.0588 x 0.1764P
  • Aspect ratio: 4:3
  • Viewing angle:
    • Up: 50°
    • Down: 70°
    • R/L: 70°
  • Rating: 20,000 hours
  • Up: 50°
  • Down: 70°
  • R/L: 70°
  • Products featured function
  • Multiple menu languages: English, Dutch, French, Portuguese, Spanish, Russian, German
  • With remote control
  • Monitors can be optional with loudspeaker or not, users can adjust sound on the control panel or remote control
  • Screen display mode can be switched the day mode and night mode by pressing button
  • Supports 2 cameras video simultaneous input
  • Supports 2 cameras audio simultaneous input
  • Normal or mirrored picture can be switched separately on each camera
  • Separate trigger control wire on each camera
  • Monitor will automatic switch-over the image to the corresponding triggered camera and back to the original mode when the trigger stops
  • The trigger delay time can be adjusted (0-4 seconds) on each camera
  • In standby mode, monitor will turn on automatically when triggered and will switch to the corresponding trigger camera image
  • Working voltage: 12-32V
  • Working current: 800mA (with in 2 cameras)
  • Self-protect of the DC voltage at the short-circuit
  • Operating temperature: -10-65°C
  • Storage temperature: -30-80°C
  • Bracket option: U/S-shape
  • Outer dimensions: 154 x 123 x 30mm
