FC-LC SM Simplex Patchcord

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

Specifications:

Simplex/duplex patch-cord available
Fan-out available
Pigtail available
Various boot (cable) sizes available
Place of origin: Shenzhen China (mainland)
Colors: yellow, orange, aqua or customized
Length: customized
Cable diameters: 0.9/1.6/1.8/2.0 and 2.4mm
Materials: PVC, LSZH, OM3, OFNR, OFNP and Plenum
Packaging: plastic bag as one standard piece or customized
Delivery detail: within 5 to 10 days

Applications:

CATV/telecommunication networks/active device termination/metro/local area networks (LANs)/data processing networks/test equipment/premise installations/wide area networks (WANs)

Features:

Low insertion loss and back reflection loss
Good exchange-ability
Good durability
High temperature stability

SM parameters:

Insertion loss: ≤0.20dB
Return loss: ≥50dB (PC) and ≥65dB (APC)
Repeatability: ≤0.1
Durability: ≤0.2 dB typical change, 1000 matings
Interchangeability: ≤0.2dB
Tensile strength: >10kg
Operating temperature: -40 to 85°C

Simplex/duplex patch-cord available

Fan-out available

Pigtail available

Various boot (cable) sizes available

Place of origin: Shenzhen China (mainland)

Colors: yellow, orange, aqua or customized

Length: customized

Cable diameters: 0.9/1.6/1.8/2.0 and 2.4mm

Materials: PVC, LSZH, OM3, OFNR, OFNP and Plenum

Packaging: plastic bag as one standard piece or customized

Delivery detail: within 5 to 10 days

CATV/telecommunication networks/active device termination/metro/local area networks (LANs)/data processing networks/test equipment/premise installations/wide area networks (WANs)

Low insertion loss and back reflection loss

Good exchange-ability

Good durability

High temperature stability

Insertion loss: ≤0.20dB

Return loss: ≥50dB (PC) and ≥65dB (APC)

Repeatability: ≤0.1

Durability: ≤0.2 dB typical change, 1000 matings

Interchangeability: ≤0.2dB

Tensile strength: >10kg

Operating temperature: -40 to 85°C
