8-channel 1.2GHz Cordless Video Transmitter and Receiver for CCTV Camera System

8-channel 1.2GHz Cordless Video Transmitter and Receiver for CCTV Camera System

Get Latest Price

Payment Type:: Wire Transfer or PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Wire Transfer or PayPal

Product Description

Professional FPV, UAV transmitter, receiver, 1.2GHz 800mW 8CHS wireless AV transmitter and receiver kit

Digital play, 8CH transmitter, credibility, synchronic, transmitting AV signal, use for mid-distance of wireless transmitting equipment

Performance parameters:

Voltage: DC 12V
Output current: 50mA
Output power: 800mW
Output frequency: 0.9/1.2/1.3G
Transmitting range: 1,600m in open fields
Video output: 1Vp-p (FM)
Audio output: 1Vp-p (FM)
Audio carrier ware: 5.5/6.0M
Weight of transmitter: 82g
Dimension of transmitter: 53*45*19mm
Operation temperatures: -10-50℃

Installing:

The line has 5 plugs for connecting transmitter, camera and power supply, one of the line's points connecting to transmitter, another has 4 plugs (red, yellow, white, black), red plug connect DC 12V/1,000mA as well as connecting battery, white and yellow plug connect to camera's audio and video apart, and black one connects camera's power input jack
Push the control button to change the channels of receiver, meanwhile, push it for several seconds firmly to close the digital play and turn into saving power model, then push it again to replay, the function is able to lock channel, so as to avoid mistaking operation

Set the same channel with transmitter and receiver

Package including:

12 channel receiver, transmitter, two pieces of small antennas, AV cable and TX cable

Applications:

If you are seeking an equipment that can transmit the audio and video to a long distance without cable, for example the villa, small lake, bridge or some other open areas
This transmitter system is the right one you need, this equipment will cover a long distance in the open area around 1,600m, but when there are obstacle between the transmitter and receiver, it will be decided case by case

Voltage: DC 12V

Output current: 50mA

Output power: 800mW

Output frequency: 0.9/1.2/1.3G

Transmitting range: 1,600m in open fields

Video output: 1Vp-p (FM)

Audio output: 1Vp-p (FM)

Audio carrier ware: 5.5/6.0M

Weight of transmitter: 82g

Dimension of transmitter: 53*45*19mm

Operation temperatures: -10-50℃

The line has 5 plugs for connecting transmitter, camera and power supply, one of the line's points connecting to transmitter, another has 4 plugs (red, yellow, white, black), red plug connect DC 12V/1,000mA as well as connecting battery, white and yellow plug connect to camera's audio and video apart, and black one connects camera's power input jack

Push the control button to change the channels of receiver, meanwhile, push it for several seconds firmly to close the digital play and turn into saving power model, then push it again to replay, the function is able to lock channel, so as to avoid mistaking operation

12 channel receiver, transmitter, two pieces of small antennas, AV cable and TX cable

If you are seeking an equipment that can transmit the audio and video to a long distance without cable, for example the villa, small lake, bridge or some other open areas

This transmitter system is the right one you need, this equipment will cover a long distance in the open area around 1,600m, but when there are obstacle between the transmitter and receiver, it will be decided case by case
