DIN/E2000 Optic Fiber Patch Cord

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or PayPal

Product Description

Features:

Specifications:

Applications:

Compliant with JIS C-5973, IEC and Bellcore

Optical performance 100% factory tested

0.9, 2.0, 2.4, 3.0mm types optional

Precision ceramic ferrule with end face geometry per IECproposal

3D interferometer used optional

Sheath of cable: PVC, LSZH or others

Compliant with RoHS Directive

Insertion loss: no more than 0.2dB (PC, UPC, APC) and no morethan 0.3dB (MM)

Return loss: more than 45dB (PC), more than 50dB (UPC) and morethan 60dB (APC)

Working temperature: -40 to +85°C

Storage temperature: -40 to +85°C

Telecommunication networks

CATV networks

Active device termination

Local area networks

FTTX
