500W/1kW/2kW/3kW/4kW Solar System for Home (Mono or Poly Panel, Gel Battery)

500W/1kW/2kW/3kW/4kW Solar System for Home (Mono or Poly Panel, Gel Battery)

Get Latest Price

Payment Type:: T/T, L/C, Western Union or Cash

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or Cash

Product Description

Features:

Solar on grid systems: solar panel + grid tie inverter
Solar off grid system: solar panel + hybird inverter (controller, inverter) + battery

System applications:

Living houses and home buildings
Office buildings, factory and warehouse
Shopping malls, venues, stadiums and more
Power stations, field operations and some huge engineer constructions

Solar panel (mono or poly panel) 200W:

Vmp: 34.4V
Voc: 43.2V
Imp: 5.2A
Weight: 15kg
Size: 1,610x670x35mm
25 years power output guarantee

PV array combiner:

H6T-96v multiple PV strings inputs
Simplify wiring between PV array and controller, protections to controller, features wide range of DC input voltage reliable thunderstorm and surge protection

Hybird solar inverter:

Inverter powers: 500W to 5kW/96V
MPPT controller model: 96V/60A
Charging efficiencies: 90 to 95%,
LCD display inverter and controller info
With built-in AC charger
Outputs: 110, 120, 220, 230 and 240V (optional)
Product size: 470x230x560mm
Weight: 49kg

Battery (lead battery or gel battery):

Capacity:12V/200Ah full sealed
Solar power lead-acid battery
Service life: 5 to 6 years
Size: 522x238x218mm
Weight: 58kg
Connecting way: 8pcs panels in series as a string, 3 strings in parallel

Solar panel rack (ground or roof type):

Ground rack installation includes complete fittings (other type of rack can be customized as per client's requirement, picture in last page)

Cable:

10mm² cables (one red and one black)
International standard, with specification suitable for solar system

Remarks:

Price for FOB or CIF
System warranty: panel 5 years, other parts 2 years
Service: during the warranty, ship the free materials for after sales service
