Solar power system, 8kW, with full accessories, free shipping, off-grid type

Solar power system, 8kW, with full accessories, free shipping, off-grid type

Get Latest Price

Payment Type:: T/T, L/C, Western Union or Cash

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or Cash

Product Description

Specifications:

Solar on-grid system: solar panel + grid tie inverter
Solar off-grid system: solar panel + hybrid inverter(controller, inverter) + battery (other parts as PV array combiner,rack, cable can optional)

System application:

Living house and home building
Office building, factory and warehouse
Shopping mall, venue, stadium and more
Power station, field operation and some huge engineerconstruction

Features:

Solar panel (mono or poly panel):
- 36pcs*200W
- Vmp: 34.4V
- Voc: 43.2V
- Imp: 5.2A
- Weight: 15kg
- Size: 1610*670*35mm
- 25 years power output guarantee
PV array combiner:
- H10T-96v multiple PV strings inputs
- Simplify wiring between PV array and controller, protections tocontroller
- Wide range of DC input voltage
- Reliable thunderstorm and surge protection
Hybrid inverter built-in solar controller:
- Inverter power: 8kW/96V
- MPPT controller model: 96V/100A
- Charging efficiency: 90-95% RH
- LCD display inverter and controller info
- With AC charger: built-in
- Output: 110V, 120V, 220V, 230V, 240V (optional)
- Product size: 590*470*730mm
- Weight: 91kg
Battery:
- Capacity: 12V/200Ah full sealed
- Solar power lead-acid battery
- Service lifespan: 5-6 years
- Size: 522*238*218mm
- Weight: 58kg
- Connect way: 8pcs panels in series as a string, 2 strings inparallel
Solar racking:
- Ground rack installation
- Including complete fittings (other type of rack can becustomized as per client's requirement)
Cable:
- 10mm² cables (one red and one black)
- International standard, with specification suitable for solarsystem

Solar on-grid system: solar panel + grid tie inverter

Solar off-grid system: solar panel + hybrid inverter(controller, inverter) + battery (other parts as PV array combiner,rack, cable can optional)

Living house and home building

Office building, factory and warehouse

Shopping mall, venue, stadium and more

Power station, field operation and some huge engineerconstruction

Solar panel (mono or poly panel):

36pcs*200W
Vmp: 34.4V
Voc: 43.2V
Imp: 5.2A
Weight: 15kg
Size: 1610*670*35mm
25 years power output guarantee

PV array combiner:

H10T-96v multiple PV strings inputs
Simplify wiring between PV array and controller, protections tocontroller
Wide range of DC input voltage
Reliable thunderstorm and surge protection

Hybrid inverter built-in solar controller:

Inverter power: 8kW/96V
MPPT controller model: 96V/100A
Charging efficiency: 90-95% RH
LCD display inverter and controller info
With AC charger: built-in
Output: 110V, 120V, 220V, 230V, 240V (optional)
Product size: 590*470*730mm
Weight: 91kg

Battery:

Capacity: 12V/200Ah full sealed
Solar power lead-acid battery
Service lifespan: 5-6 years
Size: 522*238*218mm
Weight: 58kg
Connect way: 8pcs panels in series as a string, 2 strings inparallel

Solar racking:

Ground rack installation
Including complete fittings (other type of rack can becustomized as per client's requirement)

Cable:

10mm² cables (one red and one black)
International standard, with specification suitable for solarsystem

36pcs*200W

Vmp: 34.4V

Voc: 43.2V

Imp: 5.2A

Weight: 15kg

Size: 1610*670*35mm

25 years power output guarantee

H10T-96v multiple PV strings inputs

Simplify wiring between PV array and controller, protections tocontroller

Wide range of DC input voltage

Reliable thunderstorm and surge protection

Inverter power: 8kW/96V

MPPT controller model: 96V/100A

Charging efficiency: 90-95% RH

LCD display inverter and controller info

With AC charger: built-in

Output: 110V, 120V, 220V, 230V, 240V (optional)

Product size: 590*470*730mm

Weight: 91kg

Capacity: 12V/200Ah full sealed

Solar power lead-acid battery

Service lifespan: 5-6 years

Size: 522*238*218mm

Weight: 58kg

Connect way: 8pcs panels in series as a string, 2 strings inparallel

Ground rack installation

Including complete fittings (other type of rack can becustomized as per client's requirement)

10mm² cables (one red and one black)

International standard, with specification suitable for solarsystem
