5/6kW solar power system with 25-year warranty

5/6kW solar power system with 25-year warranty

Get Latest Price

Payment Type:: T/T, L/C, Western Union or Cash

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or Cash

Product Description

Solar on-grid system: solar panel + grid tie inverter

Solar off-grid system: solar panel + hybrid inverter (controller, inverter) + battery

System applications:

Living house and home building
Office building, factory and warehouse
Shopping mall, venue, stadium and more
Power station, field operation and some huge engineer construction

SP 5kW solar system features:

Solar panel (mono or poly panel) 20pcs*200W
- Vmp: 34.4V
- Voc: 43.2V
- Imp: 5.2A
- Weight: 15kg
- Size: 1610*670*35mm
- 25-year power output guarantee
PV array combiner
- H6T-96V multiple PV strings inputs
- Simplify wiring between PV array and controller, protections to controller, features: wide range of DC input voltage, reliable thunderstorm and surge protection
Hybrid solar inverter
- Inverter power: 5kW/96V
- MPPT controller model: 96V/60A
- Charging efficiency: 90-95%
- LCD display inverter and controller info
- With AC charger built-in
- Output: 110, 120, 220, 230, 240V (optional)
- Product size: 470*230*560mm
- Weight: 49kg
Batter (lead or gel battery)
- Capacity: 12V/200Ah fully sealed*16pcs
- Solar power lead-acid battery
- Service lifespan: 5-6 years
- Size: 522*238*218mm
- Weight: 58kg
- Connecting way: 8pcs panels in series as a string, 3 strings in parallel
Solar panel rack (ground or roof type)
- Ground rack installation including complete fittings (other types of rack can be customized as per client's requirements, picture in last page)
Cable
- 10mm² cables (one red and one black)
- International standard, with specification suitable for solar system

Remarks:

Price for FOB or CIF
System warranty: panel: 5 years, other parts: 2 years
Service: during the warranty, ship the free materials for after sales service

We accept OEM and small trial orders, contact us now for more information, all inquiries will be answered within 24 hours
