LED display for dish washer

Get Latest Price

Payment Type:: L/C, T/T, PayPal, Western Union or MoneyGram

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	L/C, T/T, PayPal, Western Union or MoneyGram

Product Description

Features:

Dimension: 100.0 x 44.0mm
Colors: red, blue
Application: dish washer
Luminous evenly distributed on each segment
ISO9001-2008, SGS and comply Rohs standards
Various sizes and colors upon your option
Low power consumption
Easy to assemble on printed circuit board

Specifications:

Lens color: optional black, gray
PCB polarity: common anode/cathode
Absolute maximum ratings: (Ta=25°C)
Power dissipation: 50mW
Peak forward current: 100mA
Reverse voltage: 5V
Operating temperatures: -25°C~+85°C
Storage temperatures: -30°C~+85°C
Storage humidity range: 45~85%
Storage & soldering conditions:
- Store with care: storing the units in bad condition will causethe reflector sheet and decrease its adhesive power. Store theproducts under the following conditions: temperature (25°C± 10°C) and humidity (65°C CRH±20°C CRH)which is our recommendation
- The soldering temperature is 260±5°C, soldering timeshould be less than 3 sec and soldering iron power should be lessthan 30W
- The soldering point should be farther than 1.6mm from body

Dimension: 100.0 x 44.0mm

Colors: red, blue

Application: dish washer

Luminous evenly distributed on each segment

ISO9001-2008, SGS and comply Rohs standards

Various sizes and colors upon your option

Low power consumption

Easy to assemble on printed circuit board

Lens color: optional black, gray

PCB polarity: common anode/cathode

Absolute maximum ratings: (Ta=25°C)

Power dissipation: 50mW

Peak forward current: 100mA

Reverse voltage: 5V

Operating temperatures: -25°C~+85°C

Storage temperatures: -30°C~+85°C

Storage humidity range: 45~85%

Storage & soldering conditions:

Store with care: storing the units in bad condition will causethe reflector sheet and decrease its adhesive power. Store theproducts under the following conditions: temperature (25°C± 10°C) and humidity (65°C CRH±20°C CRH)which is our recommendation
The soldering temperature is 260±5°C, soldering timeshould be less than 3 sec and soldering iron power should be lessthan 30W
The soldering point should be farther than 1.6mm from body

Store with care: storing the units in bad condition will causethe reflector sheet and decrease its adhesive power. Store theproducts under the following conditions: temperature (25°C± 10°C) and humidity (65°C CRH±20°C CRH)which is our recommendation

The soldering temperature is 260±5°C, soldering timeshould be less than 3 sec and soldering iron power should be lessthan 30W

The soldering point should be farther than 1.6mm from body
