Product Description

Integrates voice, video, fax and unified messaging services, enabling variety voice and video terminals to access enterprise IP network and PSTN

Provides IP telephony services with highly efficient communications

Small-capacity IP PBX which is designed especially for SMB and branch offices

Provides professional IP telephony services for maximum of 1000 SIP users and 96 analog extensions, 4 E1/T1 ports for digital trunk access and 32 FXO for analog trunks

Supports 1+1 redundancy backup of power supplies

Provides high-quality built-in 64 channels audio conference and maximum of 128 concurrent calls

Capacity:

Protocol: SS7, R2, PRI, QSIG, SIP, BRI, H.323, RTMF and NO.1
Codec: G.711A/μ, G.723.1 and G.729A

Internet interfaces:

Maximum number of users: 1000 SIP users, 96 analog extensions
Port: maximum 4 E1/T1 ports, 32 FXO ports Media resources: maximum 128 concurrent calls, 64 channels audio conference
2 x RJ45 GE WAN port 1 x RJ45 FE LAN port

Call features:

Call transfer, call forward, call pickup, call restriction, abbreviated dialing, hot line, do not disturb, wake-up call, caller ID, call waiting, third-party call, blacklist and white list, one number reach you and ring group

Physical specifications:

Input: 110-240V AC
Maximum consumption: 180W
Dimensions (1.5U standard rack-mounted): 436x400x66mm
Weight: 7.5kg
Operating temperature: 0-45°C
Relative humidity: 20-90%, no condensing

Protocol: SS7, R2, PRI, QSIG, SIP, BRI, H.323, RTMF and NO.1

Codec: G.711A/μ, G.723.1 and G.729A

Maximum number of users: 1000 SIP users, 96 analog extensions

Port: maximum 4 E1/T1 ports, 32 FXO ports Media resources: maximum 128 concurrent calls, 64 channels audio conference

2 x RJ45 GE WAN port 1 x RJ45 FE LAN port

Call transfer, call forward, call pickup, call restriction, abbreviated dialing, hot line, do not disturb, wake-up call, caller ID, call waiting, third-party call, blacklist and white list, one number reach you and ring group

Input: 110-240V AC

Maximum consumption: 180W

Dimensions (1.5U standard rack-mounted): 436x400x66mm

Weight: 7.5kg

Operating temperature: 0-45°C

Relative humidity: 20-90%, no condensing
