Product Description

Specifications:

Media transfer between PSTN and IP network
Provides transform between SS7, ISDN PRI V5.2 signaling and SIP protocol 1.5 U standard rack mount

Advantages:

Modular design (two modules and each module supports maximum 4E1) complete signaling (SS7/ISDN PRI/V5.2/Q.SIG/R2/SIP/T.38) ideal trunk gateway

Descriptions:

RT-EIMS2002 is cost-effective and standard-complaint VoIP media trunk gateway
Generally called TG/SG or VoIP voice gateway, designed for enterprise users and ITSP (Internet telephony service provider) environments, locates on interface of PSTN and IP network, providing signal transform between SS7, ISDN PRI, V5.2 signaling and SIP protocol, as well as media transferring between PSTN and IP network

VoIP protocol supports:

SIP RFC3326 (reason header in SIP messages) RFC3372 (SIGTRAN and SIP-T) RFC2327 (sdp) RFC3398 (ISUP-SIP Mapping) RFC3261 (sip) RFC5806 (diversion indication in SIP) RFC2833 (DTMF ) RFC3362 (t.38) RFC 3261 (SIP 2.0) RFC3204 (MIME media types for ISUP and QSIG objects) RFC3578 (mapping of ISUP overlap to SIP)) Codec: G.711 U-law and A-law, G.711 appendix 1, G.723.1 and G.723.1 annex A, G.729 annex A and annex B, G.726, GSM, ARM and ILBC

Features:

Echo cancellation: G.168 128 ms network echo canceller Fax supports T38 and pass through 64 conference call supported Generic voice activity detection (VAD) Generic comfort noise generation (CNG) Calling control: called/calling party number translation, second stage dialing, auto-dialing with DTMF, ring back tone flexible call routing management

Capacity:

1U equipment can have 2 independent VoIP modules

Each module contains:

1-8 E1 128 G.711 channels 64 G.723, G.726, G.729 channels 32 T.38 fax channels, 64 conference bridge

Media transfer between PSTN and IP network

Provides transform between SS7, ISDN PRI V5.2 signaling and SIP protocol 1.5 U standard rack mount

Modular design (two modules and each module supports maximum 4E1) complete signaling (SS7/ISDN PRI/V5.2/Q.SIG/R2/SIP/T.38) ideal trunk gateway

RT-EIMS2002 is cost-effective and standard-complaint VoIP media trunk gateway

Generally called TG/SG or VoIP voice gateway, designed for enterprise users and ITSP (Internet telephony service provider) environments, locates on interface of PSTN and IP network, providing signal transform between SS7, ISDN PRI, V5.2 signaling and SIP protocol, as well as media transferring between PSTN and IP network

SIP RFC3326 (reason header in SIP messages) RFC3372 (SIGTRAN and SIP-T) RFC2327 (sdp) RFC3398 (ISUP-SIP Mapping) RFC3261 (sip) RFC5806 (diversion indication in SIP) RFC2833 (DTMF ) RFC3362 (t.38) RFC 3261 (SIP 2.0) RFC3204 (MIME media types for ISUP and QSIG objects) RFC3578 (mapping of ISUP overlap to SIP)) Codec: G.711 U-law and A-law, G.711 appendix 1, G.723.1 and G.723.1 annex A, G.729 annex A and annex B, G.726, GSM, ARM and ILBC

Echo cancellation: G.168 128 ms network echo canceller Fax supports T38 and pass through 64 conference call supported Generic voice activity detection (VAD) Generic comfort noise generation (CNG) Calling control: called/calling party number translation, second stage dialing, auto-dialing with DTMF, ring back tone flexible call routing management

1U equipment can have 2 independent VoIP modules

1-8 E1 128 G.711 channels 64 G.723, G.726, G.729 channels 32 T.38 fax channels, 64 conference bridge
