Ralink RT3072 WiFi Wireless Network Adapters with 150Mbps 802.11b/g/n

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T.T/Wester Union

Product Description

Main features:

With 802.11N, 300Mbps wireless USB adapter

Ralink: RT3072chipset with 2T2R modes

High peak rate WiFi adapter

Software: AP

802.11b: 1, 2, 5.5 and 11Mbps

802.11g: 6, 9, 12, 24, 36, 48 and 54Mbps

802.11n: (20MHz) MCS0-15

Supports up to 144Mbps, (40MHz) MCS0-15

Supports up to 300Mbps

With MIMO, OFDM and peak rate 300Mbps

Peak throughput: TX 80Mbps and RX 160Mbps

Power management

WiFi certification: 802.11 a/b/g, 802.11n, WPA, WPA2, WMM, WMMto PS, WHQL and Cisco CCX

Hardware:

Chip-set: Ralink RT3072

Host interface: USB2.0/1.1, type A (4-pin header)

LED link/activity

RF:

Antenna: built-in PCB on board (2T2R) (or external use Hi-rose,or compliance)

Frequencies: 2412 to 2483.5MHz and ISM band

Transmitting power: 802.11b, 17+/-1.5dBm, 802.11g and14+/-1.5dBm

802.11n: (HT20), 13+/-1.5dBm, 802.11n: (HT40) and10+/-1.5dBm

Receive sensitivity: 802.11b, -84dBm at 11Mbps, 802.11g and-68dBm at 54Mbps

802.11n: (HT20), -65dBm at MSC7, 802.11n: (HT40) and -61dBm atMSC7

Software:

Operation system: Windows CE/2000/XP/Vista, Linux & Mac OSX

Security: WEP 64/128, WPA, WPA2, 802.1x, and 802.11i Cisco CCSV1.0, 2.0 and V3.0 compliant

Operation conditions:

Voltage range: DC 5.0V ± 5%

Operating temperatures: 0 to 50°C

Storage temperatures: -20 to 70°C

Operating humility: 95% RH (non-condensing)

Storage humidity: 95% RH (non-condensing)

Dimensions: 67 x 21 x 8.5 mm
