1x16 Fan-out Fiber Optic PLC Splitter

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Product descriptions:

Fiber optic splitter is an important component in FTTX/FTTP/ FTTH/ PON, and it is used to distribute the signal from CO to number of premises

Tianyi is specialized in producing fiber optic splitter in China since 1996 With high quality the splitter is suitable to connect the central office and terminal equipment in the passive telecommunication networks (EEPON, BPON, GPON) to achieve the different optic single

We manufactures 1*N and 2*N all series products according to the requirements of customer

Product features:

Low insertion loss
Low polarization loss
High directivity
Small size
Wavelength: 1,260-1,650nm
Product specification/models
Low insertion loss
Low polarization loss
Small size

Applications:

Testing equipment FTTH&LAN
Telecommunication network system: PON
Compliance: RoHs
Telcordia GR-1209-core
·GR-1121-core

Other Information:

Parameter:
1X4
1X8
1X16
1X32
1X64
Insertion loss(dB)
With connector Max
7.4
10.9
14.3
17.2
20.4
Without connector Max:
7.2
10.7
14
17
20.2
9
Uniformity(dB):
Max
0.6
0.8
1
1.5
2
Return loss(dB):
Min
50
PDL(dB)
Max
0.25
0.3
Orientation(dB)1.3
Min
55
Dimensions :(LxWxH mm)
100 x 80 x10
120 x 80 x 18
140 x115 x 18
120 x 80 x 18
Work temperatures(°C) :-40-85
Work wavelength(nm): 1,260~1,650
Fiber length(m): 0.5,1.5 or customize
Payment: TT/LC
Delivery: 3-5days
Origin: Shenzhen
Minimum order: 10pcs
Packaging
Each packed in plastic bags with test data,all together in cartons
Inspection: RoHS/CE/SGS/ISO9001
Samples:
- Free
- Sample price
- US$0.01
- Remarks: 1x16 fanout PLC splitters fiber optic plc splitter/component in FTTX/FTTP/ FTTH/ PON

Fiber optic splitter is an important component in FTTX/FTTP/ FTTH/ PON, and it is used to distribute the signal from CO to number of premises

Low insertion loss

Low polarization loss

High directivity

Small size

Wavelength: 1,260-1,650nm

Product specification/models

Low insertion loss

Low polarization loss

Small size

Testing equipment FTTH&LAN

Telecommunication network system: PON

Compliance: RoHs

Telcordia GR-1209-core

·GR-1121-core

Parameter:

1X4

1X8

1X16

1X32

1X64

Insertion loss(dB)

With connector Max

7.4

10.9

14.3

17.2

20.4

Without connector Max:

7.2

10.7

20.2

Uniformity(dB):

Max

0.6

0.8

1.5

Return loss(dB):

Min

PDL(dB)

Max

0.25

0.3

Orientation(dB)1.3

Min

Dimensions :(LxWxH mm)

100 x 80 x10

120 x 80 x 18

140 x115 x 18

120 x 80 x 18

Work temperatures(°C) :-40-85

Work wavelength(nm): 1,260~1,650

Fiber length(m): 0.5,1.5 or customize

Payment: TT/LC

Delivery: 3-5days

Origin: Shenzhen

Minimum order: 10pcs

Packaging

Each packed in plastic bags with test data,all together in cartons

Inspection: RoHS/CE/SGS/ISO9001

Samples:

Free
Sample price
US$0.01
Remarks: 1x16 fanout PLC splitters fiber optic plc splitter/component in FTTX/FTTP/ FTTH/ PON

Free

Sample price

US$0.01

Remarks: 1x16 fanout PLC splitters fiber optic plc splitter/component in FTTX/FTTP/ FTTH/ PON
