Female Header, 5.08mm SMD Dip Type Single, 2 to 20-pin with Lift Cap in Tape and Reel
- Payment Type:
- Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Payment Type: | Telegraphic Transfer in Advance (Advance TT, T/T) |
|---|
Product Description
Product Description
- Contact: phosphor bronze
- Contact plating: Sn over 50μ" Ni
- Insulator: black polyester UL94V-0
- Standard: LCP +30％ G.F
- Current rating: 11.5 amps/contact max
- Contact resistance: ≤20mΩ/contact
- Insulation resistance: ≥1,000MΩ
- Withstanding Voltage: 1,500V AC/minute
- Lead size accepted: 1.14mmSQ
- Average insertion force: less than 15.20N
- Average withdrawal force: greater 14.55N
- Mechanical life cycle: min. 500
- Operating temperatures: -55 to 105°C
