Black Automatic Battery Charger, 72V 15A Lead Acid Battery ChargersNew

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

Quick detail:

Brand name: QUAWIN
Model number: QW720-150-S
Use: 72V lead-acid battery
Type: Electric
Place of origin: Guangdong China (Mainland)
Battery charger: automatic battery charger 88.2V
Certificates: CE, FCC, UL, SAA and RoHS
Color: Black/silver
Input voltages: AC 180～264V 45/65Hz with PFC
Output voltage: 88.2V
Output current: 15A
Output power: 1,323W
Output connector: Alligator clip, SR175A output plug, SB175A output plug, SB50A output plug, custom

Packaging & delivery:

Inner package: white box/polybags/at your request
Outer package: carton
Delivery detail: sample within 5 work days, 7~25 days for bulk order

Specifications:

Portable fast SLA/AGM/VRLA/GEL charger 72V lead acid battery charger

Features:

Fully auto CC +CV(H)+CV(L) charging process with MCU controller
Constant big charging current for faster charging
Automatically charging ending with cut-off output
Aluminum case with fan cooling
It can charge any 72V SLA/VRLA/GEL/AGM battery with capacity range 100-110Ah

Specifications:

Input: AC 180～264V 45/65Hz with PFC
Output: DC 88.2V
Charging current: 15A
Full load efficiency: ≥90%
Shock & vibration: SAEJ1378 standard
Operating temperature range: -20ºC~45ºC (-20ºF~+113ºF)
Weight: 3,000g (only body)
Dimension: 264*120*84mm
Safety protections:
- Over voltage protection
- Short circuit protection
- Polarity error protection
- Over power protection

LED indicator:

Green light on: fully charged or no connected
Blue light flash: battery is being charged
Red light on: Charger under protection (over temperature protection, output short-circuit protection, reverse polarity protection, output over-voltage protection)

Call us to know more details datasheet:

Item: QW360-280-S, QW360-290-S, QW360-300-S, QW360-310-S, QW360-320-S and QW360-330-S
Output voltage: 44.1V, 44.1V, 44.1V, 44.1V, 44.1V, 44.1V
Rated output current: 28A, 29A, 30A, 31A, 32A and 33A
Output power: 1,234.8W, 1278.9W, 1,323W, 1,367.1W, 1,411.2W, 1,455.3W
Items: QW360-340-S, QW480-210-S, QW480-220-S, QW480-230-S, QW480-240-S and QW480-250-S
Output voltages: 44.1V, 58.8V, 58.8V, 58.8V, 58.8V, 58.8V
Rated output current: 34A, 21A, 22A, 23A, 24A, 25A
Output power: 1499.4W 1234.8W 1293.6W 1352.4W 1411.2W 1470W
Items: QW600-160-S, QW600-170-S, QW600-180-S, QW600-190-S, QW600-200-S and QW720-140-S
Output voltage: 73.5V, 73.5V, 73.5V, 73.5V, 73.5V and 88.2V

Brand name: QUAWIN

Model number: QW720-150-S

Use: 72V lead-acid battery

Type: Electric

Place of origin: Guangdong China (Mainland)

Battery charger: automatic battery charger 88.2V

Certificates: CE, FCC, UL, SAA and RoHS

Color: Black/silver

Input voltages: AC 180～264V 45/65Hz with PFC

Output voltage: 88.2V

Output current: 15A

Output power: 1,323W

Output connector: Alligator clip, SR175A output plug, SB175A output plug, SB50A output plug, custom

Inner package: white box/polybags/at your request

Outer package: carton

Delivery detail: sample within 5 work days, 7~25 days for bulk order

Portable fast SLA/AGM/VRLA/GEL charger 72V lead acid battery charger

Fully auto CC +CV(H)+CV(L) charging process with MCU controller

Constant big charging current for faster charging

Automatically charging ending with cut-off output

Aluminum case with fan cooling

It can charge any 72V SLA/VRLA/GEL/AGM battery with capacity range 100-110Ah

Input: AC 180～264V 45/65Hz with PFC

Output: DC 88.2V

Charging current: 15A

Full load efficiency: ≥90%

Shock & vibration: SAEJ1378 standard

Operating temperature range: -20ºC~45ºC (-20ºF~+113ºF)

Weight: 3,000g (only body)

Dimension: 264*120*84mm

Safety protections:

Over voltage protection
Short circuit protection
Polarity error protection
Over power protection

Over voltage protection

Short circuit protection

Polarity error protection

Over power protection

Green light on: fully charged or no connected

Blue light flash: battery is being charged

Red light on: Charger under protection (over temperature protection, output short-circuit protection, reverse polarity protection, output over-voltage protection)

Item: QW360-280-S, QW360-290-S, QW360-300-S, QW360-310-S, QW360-320-S and QW360-330-S

Output voltage: 44.1V, 44.1V, 44.1V, 44.1V, 44.1V, 44.1V

Rated output current: 28A, 29A, 30A, 31A, 32A and 33A

Output power: 1,234.8W, 1278.9W, 1,323W, 1,367.1W, 1,411.2W, 1,455.3W

Items: QW360-340-S, QW480-210-S, QW480-220-S, QW480-230-S, QW480-240-S and QW480-250-S

Output voltages: 44.1V, 58.8V, 58.8V, 58.8V, 58.8V, 58.8V

Rated output current: 34A, 21A, 22A, 23A, 24A, 25A

Output power: 1499.4W 1234.8W 1293.6W 1352.4W 1411.2W 1470W

Items: QW600-160-S, QW600-170-S, QW600-180-S, QW600-190-S, QW600-200-S and QW720-140-S

Output voltage: 73.5V, 73.5V, 73.5V, 73.5V, 73.5V and 88.2V
