150W Auto Power Adapter with 11 to 16V DC Car Battery Power AC Input
  • 150W Auto Power Adapter with 11 to 16V DC Car Battery Power AC Input
150W Auto Power Adapter with 11 to 16V DC Car Battery Power AC Input

150W Auto Power Adapter with 11 to 16V DC Car Battery Power AC Input

Get Latest Price
Payment Type:
T/T or Western Union
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or Western Union
Product Description
Product Description
  • Product features:
    • Lightweight, compact design
    • RoHS power supply, fully conform to the requirements of the energy star
    • High power density
    • Super safe design, perfect protection function
  • Scope of applications:
    • Mobile device
    • LED lighting products
    • Audio and video products
    • POS machine
    • Security equipment
    • Household appliances
  • Green mode:
    • Meet CEC regulations and RoHS compliance
  • No-load power: less than 0.1W
  • Reliability
  • The average time between failures
  • At 25 degrees C ambient temperature, the maximum working load
  • The average time between failures, 5,000 hours
  • Input:
    • Input voltage: 90-264V AC
    • Frequency: 47-50/60-63HZ
    • Input current: 2.5A (maximum)100/240V AC
    • Surge current: at 100V AC, 30A maximum, at 240V AC, 60A maximum
    • Leakage current: 0.25mA maximum
  • Output:
    • Over-voltage protection
    • Over current protection: 110-200% rated load, have the function of automatic recovery
    • Short-circuit protection
    • Working temperature: 0- + 40 degrees C
    • Storage temperature: 20-+ 60 degrees C
    • Humidity enrichment conditions, humidity 5 to 95%
  • Electromagnetic interference:
    • Conduction, radiation test: CE: EN55022:2010
    • FCC: part 15
    • Harmonic testing: EN 61000-3-2:2006+A2:2009
    • Voltage change test: EN 61000-3-3:2008
  • Electromagnetic compatibility
    • Static test: EN61000-4-2
    • Radiation tolerance test: EN61000-4-3
    • Electronic rapid pulse test: EN61000-4-4
    • Lightning test: EN61000-4-5
    • Conduction resistance test: EN61000-4-6
    • Voltage dip test: EN61000-4-11
  • UL standards:
    • EN60950-1
    • UL60950-1
  • UL certification:
    • CB TUV/GS, UL/CUL, KC SAA PSE
    • CE, FCC, C-TICK
  • Lightweight, compact design
  • RoHS power supply, fully conform to the requirements of the energy star
  • High power density
  • Super safe design, perfect protection function
  • Mobile device
  • LED lighting products
  • Audio and video products
  • POS machine
  • Security equipment
  • Household appliances
  • Meet CEC regulations and RoHS compliance
  • Input voltage: 90-264V AC
  • Frequency: 47-50/60-63HZ
  • Input current: 2.5A (maximum)100/240V AC
  • Surge current: at 100V AC, 30A maximum, at 240V AC, 60A maximum
  • Leakage current: 0.25mA maximum
  • Over-voltage protection
  • Over current protection: 110-200% rated load, have the function of automatic recovery
  • Short-circuit protection
  • Working temperature: 0- + 40 degrees C
  • Storage temperature: 20-+ 60 degrees C
  • Humidity enrichment conditions, humidity 5 to 95%
  • Conduction, radiation test: CE: EN55022:2010
  • FCC: part 15
  • Harmonic testing: EN 61000-3-2:2006+A2:2009
  • Voltage change test: EN 61000-3-3:2008
  • Static test: EN61000-4-2
  • Radiation tolerance test: EN61000-4-3
  • Electronic rapid pulse test: EN61000-4-4
  • Lightning test: EN61000-4-5
  • Conduction resistance test: EN61000-4-6
  • Voltage dip test: EN61000-4-11
  • EN60950-1
  • UL60950-1
  • CB TUV/GS, UL/CUL, KC SAA PSE
  • CE, FCC, C-TICK
