ST-SC Duplex Fiber-optic Adapter, Available in Simplex and Duplex Type Metal and Plastic Version

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

SC-ST series adapter

We supply the SC-ST fiber optic adapters, including the singlemode and multi-mode types

These ST-SC fiber adapters are simplex and duplex style , mostare with zirconia sleeves, optional bronze sleeve adapters areavailable for multi-mode

Plastic and metal type are offered

Applications:

Features:

Specification:

CATV

Telecommunication networks

Local Area Networks (LANs)

Metro networks

Data processing networks

Industrial, military and medical

Adapter type: SC

Simplex or duplex versions

Compact design

High precision alignment

Low insertion and return loss and back reflection

Choice of metal or plastic housing, phosphor bronze or zirconiasplit sleeves

Hybrids available: SC/ST, SC/FC, SC/LC, SC/MU, ST/ST andothers

Insertion loss: <0.2dB

Repeatability: <0.2dB

Temperature range: -40 to 80°C

Retention force: 200 to 600g

Durability: 1,000 times
