Large Size LED Video Wall Screen, Ideal for Outdoor Advertisements, High-brightness

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

Cabinet resolution: 64 x 48 dots

Module quantity: 24 pieces

LED lamp: DIP546, oval shape

Wavelength:

Red LED: 620 to 630Nm
Green LED: 520 to 535Nm
Blue LED: 465 to 475Nm

Pixel pitch: 20mm

Pixel configuration: 2R1G1B

Module resolution: 16 x 8 dots

Screen parameters:

LED display screen resolution: 2,500 dots/m²
LED display screen brightness: 6,000 nits
Brightness adjustment: manual or automatic
Driving method: constant current/static
Viewing angle:
- Horizontal: 110°
- Vertical: 60°

Optimum viewing distance: 20 to 300m

Refreshing frequency: 1,500Hz

Power consumption:

Maximum: 1,000W/m²
Average: 400 to 800W/m²

Input voltage: 220V AC at 50Hz or 110V AC at 60Hz

Defect rate: ≤0.00001

MTBF: >5,000 hours

Lifespan: ≥100,000 hours

Protection grade: IP65

Operating temperature: -40 to 60°C

Operating humidity: 10 to 95% RH

Operating system: Microsoft Windows 98, Me, 2000, NT and XP

Cabinet frame material: black powder-coated steel

Module size: 320 x 160mm

Cabinet size: 1280 x 960mm

Cabinet weight: 57.6kg

Red LED: 620 to 630Nm

Green LED: 520 to 535Nm

Blue LED: 465 to 475Nm

LED display screen resolution: 2,500 dots/m²

LED display screen brightness: 6,000 nits

Brightness adjustment: manual or automatic

Driving method: constant current/static

Viewing angle:

Horizontal: 110°
Vertical: 60°

Horizontal: 110°

Vertical: 60°

Maximum: 1,000W/m²

Average: 400 to 800W/m²
