P10mm Outdoor LED Display Signs for Europe Market, 220/50 or 110V AC/60Hz Input VoltageNew

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

Specifications:

LED cabinet specifications (standard cabinet):

Screen parameters:

Pixel pitch: 10mm

Pixel configuration: 1R1G1B

Module resolution: 16 x 16 dots

Module size: 160 x 160mm

Cabinet size (W x H): 960 x 960mm

Cabinet resolution: 96 x 96 pixel dots

Module quantity: 36 pieces

Frame material: black powder-coated steel

Weight: 55kg

Resolution: 10,000 dots/m²

Brightness: 8,000 nits

Brightness adjustment manually or automatically

Driving method constant current: 1/4

View angles:

Optimum viewing distance: 5 to 200m

Refreshing frequency: 1,500Hz (adjustable by software)

Input voltage: 220/50 or 110V AC/60Hz

Power consumption: 1,200W/m², average: 400-800W/m² (maximum)

Defects rate: ≤0.00001

MTBF: >5,000 hours

Lifespan: ≥100,000 hours

Protection grade: IP65

Operating temperature: ﹣40 to 60°C

Operating humidity range: 10 to 95% RH

Operating system: Microsoft's Windows 98/Me/2000/NT/XP

Horizontal 110°

Vertical 60°
