P10mm LED Panel, Controlled by Software, Windows 98/Me/2000/NT/XP Operating System

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

LED module specifications:

LED cabinet specifications (standard cabinet):

Screen parameters:

Screen resolution: 10,000 dots/m²

Screen brightness: 8000 nits

Brightness adjustment: manually or automatically

Driving method: constant current 1/4

Viewing angle: horizontal 110°, vertical 60°

Optimum viewing distance: 5 to 200m

Refreshing frequency: 1500Hz (adjustable by software)

Input voltage: AC 220V/50Hz or AC 110V/60Hz

Power consumption: maximum 1,200W/m², average 400-800W/m²

Defects rate: ≤0.00001

MTBF: >5000 hours

Lifespan: ≥100,000 hours

Protection grade: IP65

Pixel pitch: 10mm

Pixel configuration: 1R1G1B

Module resolution: 16 x 16 dots

Module size: 160 x 160mm

Cabinet size (W x H): 960 x 960mm

Cabinet resolution: 96 x 96 pixel dots

Module quantity: 36pcs

Cabinet frame material: black powder-coated steel

Cabinet weight: 55kg
