LED Panel for Restaurant Advertising UseNew

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

LED pixels:

Pixel configuration: 2R1G1B

Wavelength:

R: 628 to 630nm

G: 520 to 525nm

B: 465 to 470nm

Pixel pitch: 16mm

LED module:

Module size (H x L): 128 x 256mm

Module resolution: 8 x 16 pixel dots

LED unit cabinet:

Cabinet size (L x H x D): 1,024 x 1,024 x 175D

Cabinet material: black powder coated steel

Cabinet weight: 62kg

Whole LED billboard:

LED billboard dimensions (L x H): 3,072 x 2,048mm

Square meters: 6.3

Pixel definition: 192 x 128

Cabinet quantity on the billboard: 6 pieces

Gross weight: 372kg

Packing:

Packing mode: 2 cabinets packed into one case

Packing Material: wooden case

Packing case quantity: 3 pieces

More specifications:

Pixel resolution: 3,906 dots/m²

Brightness: 9,000 nits

Color temperature: 5,000 to 9,300K (options on software)

Brightness: adjustment available by software

Viewing angle:

Horizontal: 120°

Vertical: 60°

Optimum viewing distance: 15 to 250 meters

Scanning mode: static

Driving mode: constant current

Gray grades: 4096

Displaying colors: RGB true color

Refreshing frequency: 1,500Hz

Signal interface: DVI

Input signal: RF, S-video, RGB, RGBHV, YUV, YC

Display format: 800 x 600, 1,024 x 768, 1,280 x 1024

Operating system/control software: Microsoft's Windows 98/Me/2000/NT/XP/2003

Protection grade: IP65

Working temperature: -20 to +60°C

Storage temperature: -40 to +85°C

Humidity: 10 to 95% RH

Display screen lifespan: ≥100,000 hours

MTBF: ≥5,000 hours

Power supply: 220/240V AC, 50 to 60Hz

Power consumption (maximum): 6.5kW

Power consumption (averagely): 3 to 5kW
