P6mm Indoor SMD Full Color LED Display, Screen Resolution of 27,777 Dots/m²

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

LED module specifications:

LED cabinet specifications (standard cabinet):

Screen parameters:

Pixel pitch: 6mm

Pixel configuration: RGB (SMD 3-in-1)

Module resolution: 32 dots x 16 dots

Module size: 192 x 96mm

Cabinet size (W x H): 960 x 768mm

Cabinet resolution: 160 x 128-pixel dots

Module quantity: 40pcs

Cabinet frame material: black powder-coated steel

Cabinet weight: 33kg

Screen resolution: 27,777 dots/m²

Screen brightness: 5000 nits

Brightness adjustment: manually or automatically

Driving method constant current: 1/8

View angle horizontal: 120°, vertical: 120°

Optimum viewing distance: &#gt;5m

Refreshing frequency: &#le;180Hz

Input voltage: AC 220V/50Hz or AC 110V/60Hz

Power consumption maximum: 1200W/m²

Average: 400-800W/m²

Defects rate: ≤0.00001

MTBF: >5,000 hours

Lifespan: ≥100,000 hours

Protection grade: IP43

Temperature-operating: 20-60°C

Humidity-operating: 10-95%

Operating system: Windows 98/Me/2000/NT/XP
