P6mm Rental Use, Indoor SMD Full Color LED Panel Screen, Each Cabinet Size is 576 x 576mm

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

LED module specifications:

LED cabinet specifications (standard cabinet):

Screen parameters:

Pixel pitch: 6mm

Pixel configuration: RGB (SMD 3-in-1)

Module resolution: 32 x 32 dots

Module size: 192 x 192mm

Cabinet size (W x H): 576 x 576mm

Cabinet resolution: 96 x 96 pixel dots

Module quantity: 6pcs

Cabinet frame material: black powder coated steel

Cabinet weight: 9kg

Screen resolution: 27,777 dots/m²

Screen brightness: 5,000 nits

Brightness adjustment: manually

Driving method: constant current 1/8

Viewing angle:

Optimum viewing distance: ≥5m

Refreshing frequency: ≥180Hz

Input voltage: 220V AC/50Hz or 110V AC/60Hz

Power consumption max: 1,200W/m²

Average: 400 to 800W/m²

Defects rate: ≤0.00001

MTBF: >5,000 hours

Lifespan: ≥100,000 hours

Protection grade: IP43

Operating temperature: -20 to +60°C

Operating humidity: 10 to 95%

Operating system: Windows 98/ME/2000/NT/XP

Horizontal: 120°

Vertical: 120°
