Basic Info

Payment Type:	T/T or Western Union

Product Description

Technical specifications:

LED lamps: DIP346, Oval
LEDs wavelength:
- Red: 620-630nm
- Green: 520-535nm
- Blue: 465-475nm

LED module specifications:

Pixel pitch: 16mm
Pixel configuration: 1R1G1B
Resolution: 16 x 8 pixel dots
Size: 256 x 128mm

LED cabinet specifications:

Size(WxHxD): 1,024 x 1,024 x 175mm
Resolution: 64 x 64 pixel dots
Module quantity: 32pcs
Frame material: black powder coated steel
Weight: 63kg

Screen parameters:

LED display screen resolution: 3,906 dots/¡
LED display screen brightness: 9,500 nits
Brightness adjustment: manually or automatically
Driving method: constant current/static
Viewing angle: horizontal 120°, vertical 60°
Optimum viewing distances: 15m to 300m
Refreshing frequency: 1,500Hz (adjustable by software )
Input voltage: AC220V/50Hz or AC110V/60Hz
Power consumption max.: 1500W/¡, average:500-1000W/¡
Defects rate: d0.00001
MTBF: >5000 hours
Lifespan: e100,000 hours
Protection grade: IP65
Operating temperatures: c40 to 60
Operating humidity range: 10 to 95%
Operating system: Windows98/me/2000/NT/XP

LED lamps: DIP346, Oval

LEDs wavelength:

Red: 620-630nm
Green: 520-535nm
Blue: 465-475nm

Red: 620-630nm

Green: 520-535nm

Blue: 465-475nm

Pixel pitch: 16mm

Pixel configuration: 1R1G1B

Resolution: 16 x 8 pixel dots

Size: 256 x 128mm

Size(WxHxD): 1,024 x 1,024 x 175mm

Resolution: 64 x 64 pixel dots

Module quantity: 32pcs

Frame material: black powder coated steel

Weight: 63kg

LED display screen resolution: 3,906 dots/¡

LED display screen brightness: 9,500 nits

Brightness adjustment: manually or automatically

Driving method: constant current/static

Viewing angle: horizontal 120°, vertical 60°

Optimum viewing distances: 15m to 300m

Refreshing frequency: 1,500Hz (adjustable by software )

Input voltage: AC220V/50Hz or AC110V/60Hz

Power consumption max.: 1500W/¡, average:500-1000W/¡

Defects rate: d0.00001

MTBF: >5000 hours

Lifespan: e100,000 hours

Protection grade: IP65

Operating temperatures: c40 to 60

Operating humidity range: 10 to 95%

Operating system: Windows98/me/2000/NT/XP
