Basic Info

Payment Type:	T/T, PayPal or Western Union

Product Description

Function features:

Supports USR sensor node (USR-WSD, Modbus protocol)
New Cortex-M3 kernel, industrial working temperature range, elaborate optimization LWIP protocol stack, stable and reliable
Serial port support RTS/CTS hardware flow control
Auto-MDI/MIDX function, discretionarily connect cross-over or direct network cable, automatic switching
Supports TCP Server, TCP Client, UDP, UDP Server, HTTPD Client various of work modes
Supports virtual serial work way, provide corresponding software
Serial port highest baud rate from 110bps to 1024000bps
AC 220V or DC 5V
Supports DHCP automatically access IP, can inquire the facility within network through the UDP broadcast protocol
Supply the protocol for VIP customers, can integrate parameter setting function to user software applications
Provides PC TCP/IP Socket programming example, VB, C++, Delphi, Android, IOS
Supports parameter setting via web pages, can customize web pages for users
Can also set via UDP, provide the set up protocol and software source demo code
Reload pin, pull down when power on can restore default settings
RJ45 status indicator light, RJ45 interface built-in isolation transformer, 2 KV isolation
The global only MAC address bought from IEEE, the user can modify MAC address you wanted(in misc web pages)
Supports upgrade firmware via network
Supports upgrade webpages via network
Supports IP and domain name at the same time
Supports up to 5 link from client when act as TCP server, send and receive data with or no ID
Can modify http server port for module built-in web pages
Supports Keepalive

Product characters:

Mechanical parameters: device size (LxWxH): 160x115x25mm with shell
PCB size (LxW): 150x115mm
Power supply: 220V AC plug or 5V DC
8 relay out
6 key input
1 RS232, serial to Ethernet transparent

Supports USR sensor node (USR-WSD, Modbus protocol)

New Cortex-M3 kernel, industrial working temperature range, elaborate optimization LWIP protocol stack, stable and reliable

Serial port support RTS/CTS hardware flow control

Auto-MDI/MIDX function, discretionarily connect cross-over or direct network cable, automatic switching

Supports TCP Server, TCP Client, UDP, UDP Server, HTTPD Client various of work modes

Supports virtual serial work way, provide corresponding software

Serial port highest baud rate from 110bps to 1024000bps

AC 220V or DC 5V

Supports DHCP automatically access IP, can inquire the facility within network through the UDP broadcast protocol

Supply the protocol for VIP customers, can integrate parameter setting function to user software applications

Provides PC TCP/IP Socket programming example, VB, C++, Delphi, Android, IOS

Supports parameter setting via web pages, can customize web pages for users

Can also set via UDP, provide the set up protocol and software source demo code

Reload pin, pull down when power on can restore default settings

RJ45 status indicator light, RJ45 interface built-in isolation transformer, 2 KV isolation

The global only MAC address bought from IEEE, the user can modify MAC address you wanted(in misc web pages)

Supports upgrade firmware via network

Supports upgrade webpages via network

Supports IP and domain name at the same time

Supports up to 5 link from client when act as TCP server, send and receive data with or no ID

Can modify http server port for module built-in web pages

Supports Keepalive

Mechanical parameters: device size (LxWxH): 160x115x25mm with shell

PCB size (LxW): 150x115mm

Power supply: 220V AC plug or 5V DC

8 relay out

6 key input

1 RS232, serial to Ethernet transparent
