1 to 2 VGA Extender, 100M, National Standard Lightning Protection, Noise Reduction

1 to 2 VGA Extender, 100M, National Standard Lightning Protection, Noise Reduction

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Description:

This product is 2 channel active VGA video and audio transmitters allowing remote transmission of high-resolution VGA video and high-fidelity audio over UTP cable
In addition, this product provides one channel VGA video and audio output for local use

Features:

350MHz signal transmission bandwidth
High-video resolution up to 1,600×1,200 pixels
Powered by either power adaptor or optional USB power
Transmission distance up to 150m working with UTP801AR-150
Transmission distance up to 300m working with UTP801AR-300
Support VGA, SVGA, XGA, SXGA, WXGA, UXGA and multi-sync monitors
Built-in surge and transient protection with grounding rod on front panel
Super interference rejection

Power properties:

Adaptive voltage arrange: 12V DC (power adaptor)
Power consumption: <3.5W
Connectors: DC jack, USB-B
USB protecting current: 1,000mA

Video properties:

Video input connector: 1*15-pin HD15 male, impedance: 75Ω
Local video output connector: 1*15-pin HD15 female, impedance: 75Ω
UTP cable connector: 2*RJ-45, impedance: 50Ω
Signal transmission band: >350MHz (-3dB)
Linear distortion: <3%
Synchronous signal: 0-5V, TTL PWL
Synchronous signal band: 1K-200kHz
DDC2: virtual DDC

Audio properties:

Connectors: 2* 3.5mm audio jacks
Input impedance: 10kΩ
Output impedance: 600Ω
Transmission band: 10-20kHz

Physical properties:

Dimensions (L x W x H): 210*85*32mm
Housing material: metal
Color: blue
Net weight: 540g

Environmental:

Operating temperature: 0-70°C
Relative humidity: 10-85% RH (non-condensing)
Storage temperature: -10-°C80

Accessories:

Power adaptor:
- Power supply input: 100-240V AC
- Power supply output: 12V DC/1Amp
Wire length: 2m
USB cable (A-B):
- Length: 1.5m
VGA cable (F-M):
- Length: 1.2m
Audio cable (M-M):
- Length: 1.5m
Casing gross weight: 300g
Casing volume (L x W x H): 95*97*28mm
