1 2V/1.5A Constant Current Power Supplier for LED Strips, CE-/FCC-certified/RoHS Directive Compliant

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Input voltage/frequency: 100 to 240V AC/50 or 60Hz

Output:

Protections: over-load, -voltage and short-circuit

Efficiency: 75% (minimum)

Standard DC connector: 5.5 x 2.5mm/5.5 x 2.1mm/5.5 x 1.7mm/4.8x 1.7mm/4.0 x 1.7mm/3.5 x 1.35mm/6.3 x 3.0mm with pin inside

No loading power consumption: ≤0.3W at rated voltage

Ripple and noise output voltage: 1%

High voltage test primary to secondary: 3kV, 5mA/60seconds

Leakage current: 0.5mA maximum at input 240V AC

Operating temperature range: 0 to 40°C

Storing temperature range: -20 to 85°C

High operating humidity: 40°C and 90 to 95% RH

Dimension: 29.5 x 72.5 x 48.0mm

Net weight: about 150g as per unit

MTBF: 50,000 hours

Insulation resistance: primary to secondary 50MΩ 500V DC(minimum)

Applications: water purifiers, LEDs, medical machines, CCTVcameras, LCDs, set-top boxes, DVRs, routers and modems

Packaging:

Certifications: CEC, CE (EMC, TVD), KC and FCC

Compliant with RoHS Directive

Power: 18W

Voltage: 12V DC

Current: 1,500mA

Blister (customized)

PE bag, white box and carton

PE bag, paper segment and carton
