Triode with 2.5kW Output Power, 32.5A Current and 50MHz Maximum Frequency

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

Glass triode: 1 to 30kW

Type: FU-605

Equivalent on abroad: 6T51

Output power: 2.5kW

Cathode materials: thoriated tungsten

Voltage: 6.3V

Current: 32.5A

Amplification factor: 48

Inter-electrode capacitance: PF

Cathode earthed:

Filament-grid: 12.1

Filament-anode: 0.21

Anode-grid: 6.5

Anode dissipation: 0.8kW (maximum)

Grid dissipation: 120W (maximum)

Anode DC voltage: 6kV (maximum)

Frequency: 50MHz (maximum)

Weight: 0.6kg

Additional: information here may be modified with the productsvariation

Cooling:

Triode 6T51 and FU-605 types electron tubes are glass triodeswith their anodes cooled naturally and their maximum anodedissipation powers

Mainly applied in industrial heating equipment foroscillations

F: forced air cooling

S: water cooling

Z: vapor cooling
